EATON
JDB3125 125Amp Circuit Breaker
JDB3125 125Amp Circuit Breaker
Couldn't load pickup availability
JDB3125 125Amp Circuit Breaker
The Eaton JDB3125 is a robust and reliable solution for demanding electrical applications, making it an essential component for any industrial or commercial setup. As part of Eaton's Series C, this J-frame molded case circuit breaker combines advanced engineering with practical functionality, ensuring optimal performance and safety. With a current rating of 125A, it operates efficiently at up to 600 Vac and 250 Vdc, making it suitable for various high-power applications. The breaker features fixed thermal and magnetic trips, providing consistent protection against overloads and short circuits. Its three-pole design and impressive interrupting capacity of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac guarantee robust performance in critical power distribution systems.
Key Features and Benefits:
- High Interrupting Capacity: The JDB3125 can handle up to 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, ensuring reliable performance even in high fault current conditions.
- Fixed Thermal and Magnetic Trips: These features offer dependable protection against overloads and short circuits, enhancing the safety and reliability of your electrical system.
- Versatile Voltage Ratings: Suitable for use with 600 Vac and 250 Vdc systems, making it a versatile choice for various industrial and commercial applications.
- Durable Construction: Made with high-quality materials, including aluminum terminals, ensuring longevity and consistent performance.
Technical Specifications:
- Amperage Rating: 125A
- Voltage Rating: 600 Vac, 250 Vdc
- Interrupting Capacity: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Poles: 3
- Frequency Rating: 50/60 Hz
- Trip Type: Fixed thermal, fixed magnetic
- Terminal Material: Aluminum
- Dimensions: 12 in x 6.5 in x 7 in
- Weight: 1 lb
Material Compliance and Certifications:
- Compliance: The Eaton JDB3125 circuit breaker meets stringent UL standards, ensuring it provides safe and reliable operation. Its UL listing signifies that it has been tested and meets all necessary safety and performance criteria, making it a trusted choice for critical applications.
Suitability:
- This circuit breaker is ideal for use in industrial and commercial environments where high reliability and performance are crucial. It is particularly well-suited for applications requiring high interrupting capacities and consistent protection against electrical faults. Whether you are setting up a new electrical system or upgrading an existing one, the Eaton JDB3125 offers the durability and performance you need to ensure uninterrupted power and safety.
