JD3100 100Amp Circuit Breaker

JD3100 100Amp Circuit Breaker

The Eaton JD3100 circuit breaker, part of the renowned Series C family, is engineered for robust performance and reliability, making it an essential component for your electrical protection needs. Designed with a J-frame and featuring a three-pole configuration, this circuit breaker offers a maximum amperage of 100A and can handle up to 600V AC and 250V DC. With a fixed thermal and fixed magnetic trip type, the JD3100 ensures consistent and precise protection against overloads and short circuits. Its impressive interrupting capacity of 65 kAIC at 240V AC and 35 kAIC at 480V AC makes it suitable for demanding industrial and commercial applications.

Key Features and Benefits:

• High Interrupting Capacity: With a 65 kAIC at 240V AC and 35 kAIC at 480V AC, the JD3100 is designed to handle high fault currents, ensuring safety and minimizing downtime.
• Robust Construction: The molded case construction offers durability and reliability, essential for long-term performance in harsh environments.
• Versatile Application: Ideal for industrial and commercial settings, the JD3100 supports various power distribution needs, providing flexible and reliable protection.

Technical Specifications:

• Amperage Rating: 100A
• Voltage Rating: 600V AC, 250V DC
• Frequency Rating: 50/60 Hz
• Trip Type: Fixed Thermal, Fixed Magnetic
• Interrupting Capacity: 65 kAIC at 240V AC, 35 kAIC at 480V AC
• Number of Poles: 3
• Dimensions: Length: 4.06 in, Height: 10 in, Width: 4.13 in
• Weight: 8 lbs

Material Compliance and Certifications:

• Certifications: UL Listed
• Warranty: 1-year warranty from the date of installation or 18 months from the date of shipment, whichever occurs first.
• Compliance: Eaton Selling Policy 25-000

Suitability:

• This circuit breaker is specifically designed for high-performance applications, making it an ideal choice for industries requiring reliable and efficient electrical protection. Whether in manufacturing plants, commercial buildings, or utility environments, the JD3100 offers the assurance of superior protection and operational reliability.

Ensure your electrical systems are safeguarded with the Eaton JD3100 circuit breaker, a trusted solution for modern electrical infrastructure.
