HQP3090H - 90Amp Circuit Breaker

HQP3090H - 90Amp Circuit Breaker

Looking for an Eaton HQP3090H to match a breaker already in your equipment? Start with the numbers, but don't stop there. The HQP3090H is a 90-amp, three-pole Quicklag thermal-magnetic circuit breaker rated for 240V, with a 10 kAIC interrupting rating. Those details are especially important when you're dealing with an existing or legacy electrical system, where a breaker that looks similar may not necessarily be the right fit. Check the amperage, three-pole configuration, voltage, interrupt rating, HQP type, mounting method, trip configuration, and physical dimensions against the equipment requirements before installation.

Key Features and Benefits

• 90A rating gives you a clear amperage specification to compare with the breaker being replaced.
• Three-pole design provides an important configuration checkpoint for legacy equipment.
• Quicklag thermal magnetic circuit breaker configuration matches the stated manufacturer product type.
• HQP breaker type helps narrow down the correct form and configuration during replacement work.
• Plug-on mounting makes the required mounting style clear before installation.
• Uses a non-interchangeable trip, another detail that should be matched to the equipment requirements.


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: HQP3090H

• UPC: 786679344583

• Product Name: Eaton Quicklag Thermal Magnetic Circuit Breaker

• Product Type: Thermal Magnetic Circuit Breaker

• Circuit Breaker Type: HQP

• Type: Quicklag

• Amperage Rating: 90 A

• Number of Poles: 3

• Voltage Rating: 240 V

• Interrupt Rating: 10 kAIC

• Mounting Method: Plug-on

• Trip Type: Non-Interchangeable

• Product Length/Depth: 3 in

• Product Height: 3 in

• Product Width: 3 in

• Product Weight: 1.08 lb


Material Compliance and Certifications

Manufacturer specifications identify the HQP3090H as HACR Rated, UL Listed, and CSA Certified.

Where It Works Best

The Eaton HQP3090H makes sense for compatible existing and legacy equipment that specifically calls for a 90A, three-pole HQP Quicklag thermal magnetic circuit breaker with a 240V rating, 10 kAIC interrupt rating, plug-on mounting, and non-interchangeable trip.
