HOM290 - 90 Amp Circuit Breaker

HOM290 - 90 Amp Circuit Breaker

The HOM290 is a 90 Amp, 2-pole Homeline circuit breaker for compatible Square D Homeline load centers. It is rated for 120/240V AC and plugs directly into the panel, making it a practical replacement when your existing breaker needs to match in size, rating, and fit.

With its 90A rating, the HOM290 is intended for higher-amperage 240V circuits and other applications that call for a two-pole breaker. Both poles operate together to provide the proper disconnect for the circuit.

Key Features and Benefits

• 90 Amp, 2-pole circuit breaker
• For compatible Square D Homeline load centers
• Rated for 120/240V AC
• Plug-in mounting
• HACR rated
• Occupies 2 panel spaces
• Screw-clamp terminal connection
• Accepts one 4 AWG to 2/0 AWG copper or aluminum conductor
• Useful for matching HOM290 replacement applications


Technical Specifications

• Catalog Number: HOM290

• Product Type: Miniature circuit breaker

• Product Range: Homeline

• Circuit Breaker Type: Standard

• Current Rating: 90 Amps

• Voltage Rating: 120/240V AC

• Number of Poles: 2

• Number of Spaces: 2

• Short-Circuit Current Rating: 10 kA

• Mounting Type: Plug-in

• Electrical Connection: Screw clamp terminals

• Number of Conductors: 1

• Wire Size: 4 AWG to 2/0 AWG

• Conductor Material: Copper or aluminum

• Tightening Torque: 4.8 N·m

• HACR Rated: Yes

• Operating Ambient Air Temperature: 40°C (104°F)

• Height: 79.50 mm (approximately 3.13 in.)

• Width: 50.8 mm (2.00 in.)

• Depth: 75.69 mm (approximately 2.98 in.)

• Net Weight: 0.388 kg (approximately 0.86 lb.)


Material Compliance and Certifications

The HOM290 is UL Listed and intended for use with compatible Homeline electrical equipment. It is also HACR rated.

Before installation, make sure the panel is approved for the HOM290 and that the 90 Amp rating, 2-pole configuration, 120/240V AC voltage, 10 kA short-circuit rating, and conductor range match the circuit requirements.

Where It Works Best

• Compatible Square D Homeline load centers
• 120/240V AC systems
• Circuits requiring a 90 Amp, 2-pole breaker
• Higher-amperage 240V branch circuits
• Replacement of an existing HOM290
• Homeline panel service and maintenance
• Installations requiring a 10 kA short-circuit rating
• Applications calling for a HACR-rated breaker
• Circuits using properly sized copper or aluminum conductors
• Projects where a plug-in Homeline breaker is required
