HOM270 - 70 Amp Circuit Breaker

HOM270 - 70 Amp Circuit Breaker

When you need a 70-amp breaker for a compatible Homeline load center, the HOM270 keeps things straightforward. This 2-pole, 70A circuit breaker is rated for 120/240V AC and provides standard circuit protection with a 10 kA short-circuit current rating. Its plug-in design makes it a natural fit for the Homeline system, while screw-clamp terminals accept one copper or aluminum conductor from 8 AWG through 2 AWG.

Key Features and Benefits

• 70-amp, 2-pole design for compatible 120/240V AC applications.
• Plug-in mounting is designed specifically for compatible Homeline load centers.
• Two-space configuration makes breaker requirements easy to identify when checking available panel space.
• Flexible conductor range accommodates one 8 AWG to 2 AWG copper or aluminum wire.
• Screw-clamp terminals provide a secure connection when tightened to the specified torque.
• HACR rated for applicable heating, air-conditioning, and refrigeration equipment applications.


Technical Specifications

• Catalog Number: HOM270

• Product Type: Miniature circuit breaker

• Range: Homeline

• Current Rating: 70 A

• Voltage Rating: 120/240 V AC

• Number of Poles: 2

• Number of Spaces: 2

• Circuit Breaker Type: Standard

• Short-Circuit Current Rating: 10 kA

• Mounting Type: Plug-in

• Electrical Connection: Screw-clamp terminals

• Wire Range: 1 × 8 AWG to 2 AWG

• Conductor Material: Copper or aluminum

• Tightening Torque: 4.6 N·m for 8 AWG through 2 AWG conductors

• HACR Rated: Yes

• Certification: UL Listed

• Operating Ambient Air Temperature: 40°C (104°F)

• Height: 79.50 mm

• Width: 50.8 mm

• Depth: 75.69 mm

• Net Weight: 0.327 kg (approximately 0.72 lb.)


Material Compliance and Certifications

The HOM270 is UL Listed and HACR rated. Its terminals are designed to accept either copper or aluminum conductors within the specified 8 AWG to 2 AWG range.

The supplied product information does not identify additional material-compliance certifications, so none are assumed here. For electrical equipment, sticking to documented ratings and certifications is especially important when confirming that a breaker is appropriate for a particular installation.

Where It Works Best

The HOM270 is intended for compatible Homeline load centers where the electrical design calls for a 70A, 2-pole breaker rated at 120/240V AC. It's well-suited to properly specified circuits that require a two-pole breaker with a 10 kA interrupting rating. It can also be used in applicable HACR applications when the electrical requirements match.
