HOM230GFI - 30 Amp Circuit Breaker

HOM230GFI - 30 Amp Circuit Breaker

When you need a 30-amp GFCI breaker for a compatible Homeline load center, the HOM230GFI provides ground-fault protection and standard circuit protection in a single straightforward package. This 2-pole, 120/240V circuit breaker protects against overloads and short circuits and provides Class A ground-fault protection, which trips when ground-fault current reaches 6 mA or more. It has a 10 kA short-circuit current rating and a plug-in design made specifically for compatible Homeline load centers.

Key Features and Benefits

• 30-amp, 2-pole design for compatible 120/240V AC circuits.
• Class A GFCI protection trips at a ground-fault current of 6 mA or more.
• Protects against ground faults, overloads, and short circuits.
• Convenient plug-in mounting for compatible Homeline load centers.
• Uses two spaces in the load center.
• Pigtail neutral connection for the GFCI configuration.
• Screw-clamp terminals accept specified copper or aluminum conductors.
• UL Listed for verified product certification.


Technical Specifications

• Catalog Number: HOM230GFI

• Product Type: Miniature circuit breaker

• Range: Homeline

• Current Rating: 30 A

• Voltage Rating: 120/240 VAC

• Number of Poles: 2

• Ground-Fault Protection: Class A, 6 mA

• Short-Circuit Current Rating: 10 kA

• Mounting: Plug-in

• Number of Spaces: 2

• Electrical Connection: Screw-clamp terminals

• Neutral Connection: Pigtail neutral

• Copper Wire Range: 14 AWG to 6 AWG

• Aluminum Wire Range: 12 AWG to 4 AWG

• Tightening Torque: 4.6 N·m

• Rating: HACR rated

• Certification: UL Listed

• Operating Ambient Temperature: 40°C (104°F)

• Height: 79.50 mm

• Width: 50.8 mm

• Depth: 75.69 mm

• Net Weight: 0.528 kg


Material Compliance and Certifications

The HOM230GFI is UL Listed and HACR rated. Its Class A GFCI protection is designed to trip when ground-fault current reaches 6 mA or more, providing ground-fault protection in addition to the breaker's overload and short-circuit protection.

Where It Works Best

The HOM230GFI is a good fit for compatible Homeline load centers requiring a 30A, 2-pole GFCI circuit breaker. It's designed for 120/240V AC applications that require Class A ground-fault protection, along with conventional overload and short-circuit protection.

Replacing an existing breaker? Start by checking the catalog number, but don't stop there. Make sure the application also matches the 30A current rating, 2-pole configuration, 120/240V rating, Class A GFCI protection, 10 kA short-circuit rating, conductor requirements, and load-center compatibility. That quick check can help avoid choosing a breaker that looks similar but isn't right for the application.
