HOM2200BB - 200 Amp Circuit Breaker

HOM2200BB - 200 Amp Circuit Breaker

When you need a 200-amp breaker for a compatible Homeline load center, the HOM2200BB gives you a straightforward combination of capacity, protection, and installation flexibility. That generous conductor range can make a real difference when you're working with larger wiring. The HOM2200BB occupies four spaces, provides standard circuit protection, and carries both UL Listed and HACR-rated credentials. For replacement work, maintenance, or an installation where the specifications call for a 200A, two-pole breaker, the HOM2200BB puts the essential ratings right where you need them without unnecessary complexity.

Key Features and Benefits

• 200-amp capacity: Built for applications requiring a high-current 200A circuit breaker.
• Two-pole design: Rated for 120/240 VAC electrical systems.
• Plug-in mounting: Designed to fit compatible Homeline load center equipment.
• Flexible conductor options: Accepts one 4 AWG through 300 kcmil copper or aluminum conductor.
• Four-space configuration: Occupies four spaces in the appropriate load center.
• HACR rated: Suitable where an HACR-rated breaker is specified, and all other application requirements are met.
• UL Listed: Carries recognized third-party certification.


Technical Specifications

• Catalog Number: HOM2200BB

• Product Type: Miniature Circuit Breaker

• Range: Homeline

• Breaker Type: Standard

• Current Rating: 200 A

• Number of Poles: 2

• Voltage Rating: 120/240 VAC

• Short-Circuit Current Rating: 10 kA

• Mounting Type: Plug-In

• Number of Spaces: 4

• Electrical Connection: Screw-clamp terminals/box lugs

• Wire Range: 1 × 4 AWG to 300 kcmil

• Conductor Compatibility: Copper or aluminum

• HACR Rated: Yes

• Certification: UL Listed

• Operating Ambient Temperature: 40°C (104°F)

• Height: 136.91 mm (approx. 5.39 in.)

• Width: 101.09 mm (approx. 3.98 in.)

• Depth: 79.50 mm (approx. 3.13 in.)

• Net Weight: 1.388 kg (approx. 3.06 lb.)


Material Compliance and Certifications

The HOM2200BB is UL Listed and HACR rated. Its terminals are designed to accept properly sized copper or aluminum conductors, giving installers flexibility within the specified 4 AWG to 300 kcmil conductor range.

The supplied product information does not identify additional material-compliance declarations. If a job has specific environmental or material requirements, those should be checked against the applicable product documentation before installation.

Where It Works Best

The HOM2200BB 200A circuit breaker is a strong fit for compatible Homeline load centers where the electrical system requires a 2-pole, 120/240 VAC breaker with a 10 kA short-circuit rating. It's particularly useful when replacing an existing HOM2200BB or when the equipment specifications specifically call for this breaker configuration.

Its ability to accommodate both copper and aluminum conductors also gives electricians some welcome flexibility in the field. Just as importantly, the plug-in mounting arrangement keeps the breaker configuration familiar for compatible equipment.
