HOM2200 - 200 Amp Circuit Breaker

HOM2200 - 200 Amp Circuit Breaker

When you need a 200-amp breaker for a compatible Homeline load center, the HOM2200 provides the ratings and configuration you need for the job. This 2-pole, 120/240V AC circuit breaker features plug-in mounting and a 10kA short-circuit current rating. It's built for standard circuit protection and is HACR-rated. One particularly useful feature for installers is the box-lug connection, which accepts a single copper or aluminum conductor from 4 AWG through 300 kcmil.

Key Features and Benefits

• 200A rating for electrical systems designed to use a breaker of this capacity.
• Two-pole design rated for 120/240V AC applications.
• Plug-in mounting makes the breaker straightforward to install in a compatible Homeline load center.
• Flexible conductor options with support for one copper or aluminum wire from 4 AWG to 300 kcmil.
• HACR rated, making it appropriate for qualifying heating, air-conditioning, and refrigeration applications when the equipment requirements match.
• UL Listed for easy verification of certification requirements.


Technical Specifications

• Catalog Number: HOM2200

• Product Type: Miniature circuit breaker

• Product Range: Homeline

• Current Rating: 200 A

• Voltage Rating: 120/240 V AC

• Number of Poles: 2

• Circuit Breaker Type: Standard

• Mounting Type: Plug-in

• Number of Spaces: 4

• Short-Circuit Current Rating: 10 kA

• Electrical Connection: Screw-clamp / box-lug terminals

• Conductor Capacity: 1 conductor

• Wire Range: 4 AWG to 300 kcmil copper or aluminum

• HACR Rated: Yes

• Tightening Torque: 4.8 N·m

• Height: 79.50 mm (approximately 3.13 in.)

• Width: 50.8 mm (2.00 in.)

• Depth: 75.69 mm (approximately 2.98 in.)

• Net Weight: 0.796 kg (approximately 1.75 lb.)

• Operating Ambient Air Temperature: 40°C (104°F)

• Certification: UL Listed


Material Compliance and Certifications

The HOM2200 is UL Listed and HACR rated. Its terminal arrangement accommodates either copper or aluminum conductors within the specified 4 AWG to 300 kcmil range.

Those details matter when you're matching a replacement breaker. A breaker that looks similar isn't necessarily interchangeable, so the catalog number and electrical specifications should always be checked against the equipment's requirements.

Where It Works Best

The HOM2200 200A circuit breaker is intended for use with compatible Homeline load centers requiring a two-pole, plug-in breaker rated at 120/240V AC. It's a natural fit when an existing HOM2200 needs replacement, as well as for installations specifically designed around its electrical ratings.

Because it's HACR rated, the HOM2200 can also be suitable for qualifying heating, air-conditioning, and refrigeration equipment, provided the complete system requirements match the breaker's ratings.
