HOM2175BB - 175 Amp Circuit Breaker

HOM2175BB - 175 Amp Circuit Breaker

When you need a 175-amp, 2-pole breaker for a compatible Homeline load center, the HOM2175BB gives you the essential ratings in a straightforward plug-in design. This standard miniature circuit breaker is rated for 120/240 VAC and has a 10 kA short-circuit current rating. Whether you're replacing an existing breaker or selecting equipment for a new installation, the HOM2175BB combines 175A capacity, a 2-pole configuration, a conductor range, and plug-in mounting required for compatible Homeline applications—all in one clearly specified circuit protection solution.

Key Features and Benefits

• 175 amp capacity: Designed for applications that specifically require a 175A circuit breaker.
• 2-pole configuration: Provides circuit protection for compatible 120/240VAC electrical systems.
• Simple plug-in mounting: Designed to fit compatible Homeline load centers.
• HACR rated: Suitable for qualifying heating, air-conditioning, and refrigeration applications.
• Flexible conductor options: Accepts both copper and aluminum wire from 4 AWG through 300 kcmil.
• Secure terminal connection: Screw-clamp terminals help provide a dependable electrical connection.


Technical Specifications

• Catalog Number: HOM2175BB

• Product Type: Miniature circuit breaker

• Product Range: Homeline

• Current Rating: 175 A

• Voltage Rating: 120/240 V AC

• Number of Poles: 2

• Short-Circuit Current Rating: 10 kA

• Circuit Breaker Type: Standard

• Mounting Type: Plug-in

• Number of Spaces: 4

• Electrical Connection: Screw-clamp terminals

• Conductor Capacity: 1 conductor

• Wire Range: 4 AWG to 300 kcmil, copper or aluminum

• HACR Rated: Yes

• Tightening Torque: 28.3 N·m for 4/0 AWG to 250 kcmil

• Height: 136.91 mm (approximately 5.39 in.)

• Width: 101.09 mm (approximately 3.98 in.)

• Depth: 79.50 mm (approximately 3.13 in.)

• Net Weight: 1.361 kg (approximately 3.0 lb.)

• Operating Ambient Air Temperature: 40°C (104°F)


Material Compliance and Certifications

The HOM2175BB is UL Listed and HACR rated. Its terminals are designed to accommodate either copper or aluminum conductors, provided the conductor falls within the specified 4 AWG to 300 kcmil range.

The supplied manufacturer information does not identify any additional material compliance certifications, so claims beyond the documented certifications have been intentionally omitted.

Where It Works Best

This breaker is a strong fit when the job calls for a 175A, 2-pole, 120/240VAC breaker in a compatible Homeline load center. It can be used for qualifying residential or other electrical applications where its voltage, amperage, interrupting rating, conductor range, and HACR rating meet the system requirements.

For replacement work, don't choose a breaker based on amperage and physical appearance alone. Check the load center requirements and verify the catalog number, 2-pole configuration, 175A rating, 120/240VAC rating, 10kA short-circuit rating, four-space design, conductor requirements, and plug-in mounting before installation. That quick compatibility check can prevent a lot of headaches once the job is underway.
