HOM2175 - 175Amp Circuit Breaker

HOM2175 - 175Amp Circuit Breaker

Need a 175-amp main circuit breaker for a compatible Type HOM panel? The HOM2175 is a 2-pole, plug-in thermal-magnetic breaker rated for 120/240 VAC service. With a 10k AIC rating, it provides overload and short-circuit protection for your electrical systems that match its ratings and configuration. It's also HACR Type, making it suitable for heating, air-conditioning, and refrigeration applications.

Key Features and Benefits

• 175-amp capacity for applications requiring a 175-amp main circuit breaker.
• 2-pole design for compatible 120/240VAC electrical systems.
• Thermal magnetic operation protects against both overload and short-circuit conditions.
• Plug-in design for use with compatible Type HOM equipment.
• HACR Type, making it appropriate for qualifying heating, air-conditioning, and refrigeration applications.
• Designed as a main circuit breaker.


Technical Specifications

• Part Number: HOM2175

• Type: HOM

• Breaker Type: Thermal Magnetic Main Circuit Breaker

• Amperage: 175 A

• Number of Poles: 2

• Voltage Rating: 120/240VAC

• A.I.C. Rating: 10k @ 120/240VAC

• Mounting Style: Plug-In

• HACR Type: Yes

• Panel Space Required: Four (4) 1-pole spaces

• Height: 3.5 in.

• Width: 4.0 in.

• Depth: 2.69 in.


Material Compliance and Certifications

The available product specifications identify the HOM2175 as HACR Type. This designation supports its use in applicable heating, air-conditioning, and refrigeration equipment when the application's electrical requirements match the breaker.

No additional material-compliance or certification information was provided in the supplied specifications, so unsupported UL, CSA, RoHS, or other certification claims should not be added to the product description.

Where It Works Best

The HOM2175 is a practical fit for compatible Type HOM electrical panels that call for a 175 amp, 2-pole main circuit breaker rated at 120/240VAC and 10k AIC. It can also be used in appropriate HACR applications that require the same electrical specifications.

For replacement work, don't rely on amperage alone. Check the existing breaker and panel requirements carefully, including the HOM type, 2-pole configuration, voltage, interrupting rating, plug-in mounting style, and four-space requirement. Getting those details right is what matters when matching a circuit breaker to the intended electrical system.
