HOM125 - 25 Amp Circuit Breaker

HOM125 - 25 Amp Circuit Breaker

Enhance your electrical panel’s performance and protection with the HOM125 Miniature Circuit Breaker, part of the Homeline® series — a high-quality 25-amp, single-pole unit designed for 120/240 V AC systems. Whether you’re an electrician outfitting a residential panel or a facility manager specifying breakers for light-commercial use, this breaker delivers dependable overload and short-circuit protection with plug-in simplicity. It features a compact form factor and accepts both copper and aluminum wiring, making it a versatile choice for new installations or upgrades where space, ease of install and code-compliance matter.

Key Features and Benefits

• 25 A current rating at 120/240 VAC: ideal for branch circuit protection in homes, apartments, workshops and light commercial spaces.
• 10 kA interrupting rating: handles significant fault current without compromise.
• Plug-in mounting: enables fast & secure installation into Homeline load centres, reducing labor and panel downtime.
• Clamp-style terminal: accepts 14 AWG to 8 AWG copper or aluminum (one wire) or dual copper up to 10 AWG — flexible for varied wiring configurations.
• Compact footprint (≈ 3.13″ H × 1.0″ W × 2.98″ D): fits cleanly within standard breaker spaces.
• Lifetime warranty: backed by Schneider Electric’s limited lifetime coverage (check terms) for added peace-of-mind.

Technical Specifications

• Product Type: Miniature Circuit Breaker (MCB)
• Range: Homeline® series
• Current Rating: 25 A
• Voltage Rating: 120/240 VAC
• Number of Poles: 1
• Interrupting Rating (short-circuit current rating): 10 kA (10,000 AIR)
• Mounting Type: Plug-in
• Electrical Connection: Clamp terminal (2 cables)
• Wire Size: 1 × AWG 14–8 (aluminium/copper); 2 × AWG 14–10 (copper)
• Tightening Torque: 4.0 N·m (2.5…6 mm² / AWG 14…8)
• Dimensions: 79.50 mm (H) × 25.40 mm (W) × 75.69 mm (D) (~3.13″ × 1.0″ × 2.98″)
• Ambient Operating Temperature: up to 40 °C
• Certifications: UL-listed and HACR-rated for HVAC compatibility
• Environmental Compliance: Schneider Electric “Green Premium” — RoHS-compliant, REACh-certified, mercury- and heavy-metal-free, packaged with at least 70% recycled cardboard (depending on region).

Where It Works Best

• Use the HOM125 in residential load centres, garages, outdoor workshops, small-office build-outs or light-commercial branch circuits where a one-pole, 25 A breaker is needed. Its plug-in design and broad wire-size acceptance make it ideal for retrofit or panel-upgrade applications: when you want a reliable circuit protection solution that won’t complicate installation. Fit it when you’re protecting lighting circuits, small HVAC units, receptacle zones or sub-panels that require dependable protection without going over-engineered.
