HMDL3350L 350A Circuit Breaker

HMDL3350L 350A Circuit Breaker

The Eaton HMDL3350L Series C molded case circuit breaker is designed to provide outstanding performance and reliability in demanding electrical environments. With a robust three-pole configuration, this breaker supports a rated current of 350A and boasts an impressive interrupting capacity of 100kAIC at 240VAC and 65kAIC at 480VAC, making it an ideal choice for high-fault conditions typically found in industrial and commercial power distribution systems.

Key Features and Benefits:

• High Interrupting Capacity: Handles up to 100kAIC at 240VAC and 65kAIC at 480VAC, ensuring reliable protection in high-fault conditions.
• Durable Construction: Engineered for the rigorous demands of industrial applications, ensuring long-lasting reliability and performance.
• Easy Installation: Designed with standard dimensions and weight for straightforward installation and integration into existing systems.

Technical Specifications:

• Rated Current: 350A
• Poles: 3
• Voltage Rating: 240/480VAC
• Interrupting Rating: 100kAIC at 240VAC, 65kAIC at 480VAC
• Frequency: 50/60 Hz
• Dimensions (L x W x H): 18 x 8 x 11 inches
• Weight: 20 lbs
• Special Features: Line and Load Lug Terminals

Material Compliance and Certifications:

• UL Listed: Meets stringent safety and performance standards for reliable operation.
• RoHS Compliance: Manufactured in accordance with the Restriction of Hazardous Substances directive, ensuring minimal environmental impact.

Suitability:

• The Eaton HMDL3350L circuit breaker is ideally suited for use in commercial and industrial settings where high reliability and protection are essential. Its high interrupting capacity makes it particularly suitable for environments with significant electrical load and potential fault conditions, such as manufacturing facilities, data centers, and large commercial buildings.
