HFD3125 - 125Amp Circuit Breaker (Blue label)

HFD3125 - 125Amp Circuit Breaker (Blue label)

The Cutler Hammer HFD3125 Series C molded case circuit breaker is a robust and reliable solution designed to provide superior protection for electrical circuits. As part of Cutler Hammer's renowned Series C, the HFD3125 features a three-pole configuration with a fixed thermal and fixed magnetic trip type, ensuring dependable performance in various applications. Rated for 125 amperes with a voltage rating of 600 VAC and 250 VDC, this circuit breaker is ideal for use in commercial and industrial settings.

Key Features and Benefits

• High Interrupting Capacity: 100 kAIC at 240 VAC and 65 kAIC at 480 VAC for enhanced protection against short circuits.
• Compact Design: Dimensions of 3.38 x 4.13 x 4.13 inches ensure it fits into tight spaces, ideal for retrofit applications.
• Fixed Thermal and Magnetic Trip: Provides consistent performance and reliable protection.
• Durable Construction: Built to withstand harsh industrial environments, ensuring long-term reliability.
• Warranty: One-year warranty from installation or eighteen months from shipment, underscoring Cutler Hammer's commitment to quality.

Technical Specifications

• Amperage Rating: 125 A
• Voltage Rating: 600 VAC, 250 VDC
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 100 kAIC at 240 VAC, 65 kAIC at 480 VAC
• Poles: Three-pole
• Dimensions: 3.38 in (L) x 4.13 in (H) x 4.13 in (W)
• Weight: 4.25 lbs
• Frequency: 50/60 Hz
• Terminals: Load side

Material Compliance and Certifications

• Certifications: UL Listed
• Material Compliance: Meets industry standards for safety and reliability, ensuring compliance with local and international regulations.

Suitability

• The Cutler Hammer HFD3125 circuit breaker is suitable for a wide range of applications including industrial control panels, commercial buildings, and machinery protection. Its high interrupting capacity makes it particularly well-suited for environments with high fault currents. The compact design allows for easy integration into existing systems, making it an excellent choice for both new installations and upgrades.
