HFD3100 - 100Amp Circuit Breaker

HFD3100 - 100Amp Circuit Breaker

The Eaton HFD3100 is a top-of-the-line molded case circuit breaker from the Eaton Series C, designed to provide reliable and efficient circuit protection for commercial and industrial applications. This robust F-frame circuit breaker is engineered to handle demanding electrical environments, offering both fixed thermal and magnetic trip types for enhanced performance and safety. With a three-pole configuration, it is rated for 100 amperes and supports a voltage of 600 Vac and 250 Vdc, making it suitable for a wide range of electrical systems.

Key Features and Benefits

• High Current Rating: The HFD3100 handles up to 100 A, ensuring it can manage substantial electrical loads, which is ideal for heavy-duty applications.
• Versatile Voltage Compatibility: Supports 600 Vac and 250 Vdc, making it adaptable to both AC and DC electrical systems.
• Fixed Thermal and Magnetic Trips: Provides consistent protection by automatically tripping in overcurrent situations, safeguarding equipment and enhancing operational safety.
• Robust Construction: Built with durable materials to withstand harsh industrial environments, ensuring longevity and reliability.

Technical Specifications

• Series: Eaton Series C
• Frame Type: F-frame
• Amperage Rating: 100 A
• Voltage Rating: 600 Vac, 250 Vdc
• Trip Type: Fixed Thermal, Fixed Magnetic
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
• Poles: Three-pole
• Dimensions: 3.38 in (Length), 6 in (Height), 4.13 in (Width)
• Weight: 4.3 lb

Material Compliance and Certifications

• Certifications: UL Listed, ensuring adherence to recognized safety standards and regulatory compliance.

Suitability

• The Eaton HFD3100 circuit breaker is ideal for use in commercial and industrial settings where reliable circuit protection is crucial. It is particularly suited for applications involving large machinery, HVAC systems, and other equipment requiring high current capacity and robust protection mechanisms. Its high interrupting capacity ensures it can safely manage fault conditions without compromising system integrity.
