When you’re replacing a circuit breaker in existing equipment, the details matter. The Eaton HFD3090L is a 90-amp, three-pole molded case circuit breaker from the Eaton Series C HFD family, built around the F frame. It carries voltage ratings of 600 VAC and 250 VDC and operates at 50/60 Hz. For fault-current requirements, the HFD3090L is rated 100 kAIC at 240 VAC and 65 kAIC at 480 VAC. It also uses the T186 trip type and comes with line and load terminals. Those specifications are especially useful when you're trying to match an existing breaker rather than simply finding another 90A unit.

Key Features and Benefits

• 90-amp, three-pole configuration for compatible three-pole electrical applications.
• Part of the Eaton Series C HFD molded case circuit breaker family.
• Uses an F frame and T186 trip type.
• Rated for 600 VAC and 250 VDC.
• Designed for 50/60 Hz electrical systems.
• Includes line and load terminals.
• Supplied as a complete breaker, not simply an individual breaker component.
• UL Listed for applications requiring this certification.

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: HFD3090L

• UPC: 786679175170

• Product Type: Molded case circuit breaker

• Series: Series C

• Breaker Type: HFD

• Frame: F

• Frame Type: Complete breaker

• Amperage Rating: 90 A

• Number of Poles: 3

• Voltage Rating: 600 VAC, 250 VDC

• Trip Type: T186

• Frequency Rating: 50/60 Hz

• Interrupt Rating at 240 VAC: 100 kAIC

• Interrupt Rating at 480 VAC: 65 kAIC

• Terminals: Line and load

• Height: 6 in.

• Width: 4.13 in.

• Depth: 3.38 in.

• Weight: 4.55 lb


Material Compliance and Certifications

The Eaton HFD3090L is UL Listed. That makes the certification easy to identify when reviewing a breaker against the requirements of an existing electrical system or project. No additional material-compliance certifications were identified in the supplied product specifications, so any project-specific environmental or material requirements should be checked separately.

Where It Works Best

The HFD3090L makes the most sense in commercial and industrial electrical equipment designed to accept an Eaton Series C HFD F-frame molded case circuit breaker with these ratings and dimensions. It's particularly relevant for maintenance and replacement jobs where matching the existing breaker’s form, fit, and function is important.
