HFD3080L - 80Amp Circuit Breaker

HFD3080L - 80Amp Circuit Breaker

When you’re replacing a circuit breaker in existing equipment, the details have to line up. The Eaton HFD3080L is an 80-amp, three-pole molded case circuit breaker from the Series C HFD family. It’s an F-frame complete breaker rated for 600 VAC and 250 VDC, with a T186 trip type and line and load terminals. Built to last and designed for its intended Series C applications, this breaker is a practical choice when keeping an existing electrical system in its specified configuration matters.

Key Features and Benefits

• Designed for applications requiring an 80-amp molded case circuit breaker.
• Fits compatible three-phase electrical systems requiring a three-pole breaker.
• Intended for equipment designed around the HFD breaker family.
• F-frame construction
• 600 VAC / 250 VDC rating
• Defined interrupt ratings: Rated 100 kAIC at 240 VAC and 65 kAIC at 480 VAC.
• Helps maintenance personnel match the breaker to the required trip configuration.
• Supplied as a complete molded case circuit breaker rather than an individual breaker component.
• Line and load terminals
• UL Listed

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: HFD3080L

• UPC: 786679175163

• Product Type: Molded case circuit breaker

• Series: Series C

• Breaker Type: HFD

• Frame: F

• Frame Type: Complete breaker

• Amperage Rating: 80 A

• Number of Poles: Three-pole

• Voltage Rating: 600 VAC, 250 VDC

• Trip Type: T186

• Frequency Rating: 50/60 Hz

• Interrupt Rating at 240 VAC: 100 kAIC

• Interrupt Rating at 480 VAC: 65 kAIC

• Terminals: Line and load

• Height: 6 in.

• Width: 4.13 in.

• Depth: 3.38 in.

• Weight: 4.45 lb


Material Compliance and Certifications

The HFD3080L is UL Listed. That’s an important specification when you're matching a replacement breaker for equipment or an installation that calls for a UL-listed device. No additional material-compliance certifications are stated in the supplied manufacturer specifications, so project-specific compliance requirements should be checked separately when applicable.

Where It Works Best

The HFD3080L makes the most sense in commercial and industrial electrical equipment designed to accept a Series C HFD F-frame, 80A, three-pole molded case circuit breaker. It can be particularly useful in maintenance and replacement situations where an existing system needs to remain within its specified configuration rather than be altered.
