HFD3060L - 60Amp Circuit Breaker

HFD3060L - 60Amp Circuit Breaker

When your existing electrical system calls for a specific breaker, getting the details right matters. The Eaton HFD3060L is a 60-amp, three-pole Series C molded case circuit breaker built around the HFD F-frame configuration. Rated for 600 VAC and 250 VDC, it uses a T186 trip type and operates at 50/60 Hz. Its interrupt ratings are 100 kAIC at 240 VAC and 65 kAIC at 480 VAC. Unlike configurations supplied with terminals on only one side, the HFD3060L is specified with line and load terminals, an important point to check when matching an existing installation.

Key Features and Benefits

• 60A three-pole configuration
• Matches applications specifically designed around the HFD breaker family and F-frame configuration.
• Line and load terminals
• 600 VAC / 250 VDC rating
• Helps maintenance personnel accurately match the required breaker configuration.
• Rated at 100 kAIC at 240 VAC and 65 kAIC at 480 VAC.
• Complete breaker configuration

Technical Specifications

• Product Name: Eaton Series C complete molded case circuit breaker

• Catalog Number: HFD3060L

• UPC: 786679175149

• Product Type: Molded case circuit breaker

• Series: Series C

• Circuit Breaker Type: HFD

• Frame: F

• Circuit Breaker Frame Type: Complete breaker

• Amperage Rating: 60 A

• Number of Poles: Three-pole

• Voltage Rating: 600 VAC, 250 VDC

• Trip Type: T186

• Frequency Rating: 50/60 Hz

• Interrupt Rating at 240 VAC: 100 kAIC

• Interrupt Rating at 480 VAC: 65 kAIC

• Terminals: Line and load

• Product Height: 6 in.

• Product Width: 4.13 in.

• Product Length/Depth: 3.38 in.

• Product Weight: 4.5 lb


Material Compliance and Certifications

The Eaton HFD3060L is UL Listed, providing a documented certification point when evaluating the breaker for an applicable electrical installation. No additional material-compliance certifications are specified in the provided product information, so any project-specific compliance requirements should be checked separately.

Where It Works Best

The HFD3060L molded case circuit breaker is a practical fit for maintenance and replacement work involving compatible Series C HFD F-frame electrical equipment. It's especially useful when the existing application requires a 60A, three-pole breaker with line-and-load terminals and the same defined voltage, trip, frequency, and interrupt ratings.
