HFD3060 - 60Amp Circuit Breaker

HFD3060 - 60Amp Circuit Breaker

The Eaton HFD3060 is a 60-amp, three-pole molded case circuit breaker made for Series C HFD applications that call for an F-frame complete breaker. For anyone maintaining your existing electrical system, the details matter—and this breaker gives you a clearly defined set of ratings to work with. It is rated for 600 VAC and 250 VDC, operates at 50/60 Hz, and uses a T186 trip type.

Key Features and Benefits

• 60-amp rating
• Three-pole design
• Series C HFD breaker
• T186 trip type
• Rated for 600 VAC and 250 VDC.
• Rated at 100 kAIC at 240 VAC and 65 kAIC at 480 VAC.
• Load-side terminals

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: HFD3060

• UPC: 786679175866

• Product Type: Molded case circuit breaker

• Series: Series C

• Breaker Type: HFD

• Frame: F

• Frame Type: Complete breaker

• Amperage: 60 A

• Poles: Three

• Voltage Rating: 600 VAC, 250 VDC

• Trip Type: T186

• Frequency: 50/60 Hz

• Interrupt Rating: 100 kAIC at 240 VAC

• Interrupt Rating: 65 kAIC at 480 VAC

• Terminals: Load side

• Height: 6 in.

• Width: 4.13 in.

• Depth: 3.38 in.

• Weight: 4.4 lb


Material Compliance and Certifications

The HFD3060 is UL Listed, giving installers and maintenance teams a clear certification reference when checking the breaker against equipment or project requirements. No other material-compliance certifications are identified in the provided product specifications, so requirements beyond the stated UL listing should be confirmed for the particular installation.

Where It Works Best

The Eaton HFD3060 circuit breaker makes the most sense in existing commercial or industrial electrical equipment that already calls for a 60A, three-pole Series C HFD F-frame breaker. It's particularly relevant for maintenance and replacement jobs where keeping the original breaker configuration is the goal.
