HFD3020 20A Circuit Breaker

HFD3020 20A Circuit Breaker

The Eaton HFD3020 Series C molded case circuit breaker is an essential component for any electrical system requiring reliable protection and superior performance. This three-pole, 20-amp circuit breaker is designed to provide both fixed thermal and magnetic trip functionalities, ensuring safety and efficiency in various applications.

Key Features and Benefits:

• Robust Design: The Eaton HFD3020 is part of the renowned Series C line, known for its durable construction and dependable performance. It features a molded case that provides enhanced protection and longevity.
• High Interrupting Capacity: With an interrupting capacity of 65 kAIC at 480 Vac and 100 kAIC at 240 Vac, this circuit breaker can handle significant electrical faults, minimizing the risk of equipment damage.
• Fixed Thermal and Magnetic Trip: The fixed thermal and magnetic trip functions ensure precise and automatic disconnection during overcurrent situations, protecting your electrical system from potential hazards.
• Versatile Applications: Suitable for a wide range of environments, including industrial, commercial, and residential settings. Ideal for protecting circuits in load centers, panelboards, switchboards, and more.

Technical Specifications:

• Amperage Rating: 20A
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupting Rating: 65 kAIC at 480 Vac, 100 kAIC at 240 Vac
• Trip Type: Fixed Thermal, Fixed Magnetic
• Frame Type: F-Frame
• Number of Poles: Three
• Frequency Rating: 50/60 Hz
• Dimensions: 3.38 in (Length) x 6 in (Height) x 4.13 in (Width)
• Weight: 4.35 lb

Material Compliance and Certifications:

• The Eaton HFD3020 circuit breaker is UL Listed, ensuring it meets all necessary safety and performance standards.

Suitability:

• The HFD3020 is engineered for a variety of applications, making it a versatile choice for electrical contractors and engineers. It is ideal for use in settings where reliability and safety are paramount, such as manufacturing facilities, commercial buildings, and residential complexes. Whether you are upgrading an existing system or installing a new one, the Eaton HFD3020 circuit breaker provides the protection and performance you need to ensure uninterrupted operation.
