HED43B060 - 60Amp Circuit Breaker

HED43B060 - 60Amp Circuit Breaker

The Siemens HED43B060 is a high-performance, low voltage Sentron molded case circuit breaker designed for a wide range of applications. This breaker is equipped with a thermal-magnetic trip unit, ensuring reliable protection against overcurrent conditions and short circuits. With a high breaking capacity and robust construction, the HED43B060 is ideal for commercial and industrial use.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides dual protection with a thermal mechanism for overload conditions and a magnetic mechanism for short circuits, ensuring safety and reliability.
• High Breaking Capacity: With a breaking capacity of 42kA at 480V, this breaker can handle high fault currents, making it suitable for demanding applications.
• Compliance and Standards: Meets UL 489 and IEC 60947-2 standards, ensuring it adheres to stringent international safety and performance guidelines.
• Durable Construction: Designed with an ED frame and standard 40å¡C rating, this circuit breaker offers enhanced durability and operational efficiency.
• Load Lugs Only: Equipped with LN1E100 load lugs, supporting wire ranges from 10 AWG to 1/0 AWG (copper/aluminum), facilitating flexible and secure connections.
• Compact Dimensions: Measuring 3 x 6.35 x 3.92 inches, this breaker fits easily into standard panelboards and switchboards, optimizing space and installation convenience.

Technical Specifications:

• Current Rating: 60A
• Poles: 3
• Voltage Rating: 480V AC
• Breaking Capacity: 42kA at 480V
• Dimensions: 3 inches (W) x 6.35 inches (H) x 3.92 inches (D)
• Weight: 3.75 lbs
• Wire Range: 10 - 1/0 AWG (Copper/Aluminum)

Material Compliance and Certifications:

• UL 489: Certified for safety and performance.
• IEC 60947-2: Compliant with international electrical equipment standards.
• RoHS Directive: Compliant since April 2, 2009, ensuring the absence of hazardous substances.
• WEEE Directive: Adheres to the EU‰۪s Waste Electrical and Electronic Equipment Directive for responsible recycling and disposal.

Suitability:

• The Siemens HED43B060 circuit breaker is designed for use in commercial and industrial electrical systems, including panelboards, switchboards, and control panels.
• Its high breaking capacity and robust design make it suitable for protecting electrical circuits in manufacturing plants, commercial buildings, and other high-demand environments.
• This breaker is also a perfect choice for applications requiring reliable performance and compliance with international safety standards.

Ensure your electrical system is protected with the Siemens HED43B060, a circuit breaker that combines durability, safety, and advanced features to meet the highest industry standards.
