The Siemens HED43B015L is a 15 Amp, 3-pole molded case circuit breaker from the SENTRON ED frame family. Designed for 480VAC electrical distribution systems, it combines thermal and magnetic trip protection to help safeguard equipment against overloads and short circuits. Its 42kA interrupting capacity at 480VAC makes it suitable for applications where higher fault current ratings are required.

Whether you're replacing an existing breaker during maintenance or keeping compatible spare inventory on hand, the HED43B015L is intended to match the original equipment's form, fit, and function.

Key Features and Benefits

• Siemens SENTRON ED frame molded case circuit breaker
• 15 Amp current rating
• Three-pole configuration for three-phase systems
• Thermal magnetic trip mechanism
• Rated for 480VAC applications
• Includes line and load side lugs (SA1E025)
• Accepts 14–10 AWG copper conductors
• Accepts 12–10 AWG aluminum conductors
• Standard 40°C calibration
• Designed as a form, fit, and function replacement for compatible Siemens equipment

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: HED43B015L

• Product Family: SENTRON

• Product Type: Molded Case Circuit Breaker

• Frame: ED

• Amperage: 15 Amps

• Poles: 3

• Voltage Rating: 480VAC

• Trip Unit: Thermal Magnetic

• Interrupting Rating: 42kAIC @ 480VAC

• Terminals: Line and Load Side Lugs (SA1E025)

• Copper Wire Range: 14–10 AWG

• Aluminum Wire Range: 12–10 AWG

• Operating Temperature: Standard 40°C

• Dimensions: 3 in. W × 6.35 in. H × 3.92 in. D

• Weight: 3.527 lbs

• Country of Origin: Mexico


Material Compliance and Certifications

The Siemens HED43B015L is manufactured to comply with UL 489 and IEC 60947-2 standards for molded case circuit breakers.

Where It Works Best

The HED43B015L is commonly used in commercial and industrial electrical distribution systems operating on 480VAC three-phase power.
