HED41B060 - 60Amp Circuit Breaker

HED41B060 - 60Amp Circuit Breaker

The Siemens HED41B060 is a top-tier low voltage SENTRON molded case circuit breaker designed to meet the rigorous demands of commercial and industrial applications. Engineered with a thermal-magnetic trip unit, this circuit breaker ensures reliable performance and protection against overloads and short circuits. With its robust ED frame, this breaker provides high breaking capacity and exceptional durability, making it an ideal choice for ensuring electrical safety and continuity.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Offers precise protection by combining thermal and magnetic trip mechanisms to safeguard against both overloads and short circuits.
• High Breaking Capacity: Ensures reliable interruption of high fault currents up to 25kA at 277V, enhancing safety and system stability.
• Standard 40å¡C Breaker ED Frame: Built for high-performance scenarios, ensuring consistent operation even in challenging environments.
• Compact Design: With dimensions of 1 x 6.35 x 3.92 inches, the HED41B060 is compact yet powerful, making it easy to install in various panel boards and distribution systems.
• Load Lugs Only (LD1E060): Simplifies installation with load lugs designed to accommodate wire ranges from 10 to 4 AWG (CU/AL).

Technical Specifications:

• Ampere Rating: 60A
• Number of Poles: 1
• Interrupting Rating: 25kA at 277V
• Standards Compliance: Meets UL 489 and IEC 60947-2 standards
• Dimensions: 1 x 6.35 x 3.92 inches (W x H x D)
• Wire Range: 10 - 4 AWG (CU/AL)
• Net Weight: 1.1 lb

Material Compliance and Certifications:

• RoHS Compliance: The Siemens HED41B060 circuit breaker complies with the RoHS directive, ensuring it is free from hazardous substances since March 31, 2009.
• WEEE Compliance: Additionally, it fulfills the requirements of the WEEE directive (2012/19/EU), ensuring responsible recycling and disposal of electrical and electronic equipment.
• REACH Compliance: The breaker also adheres to REACH regulations, reflecting Siemens' commitment to environmental protection and sustainability.

Suitability:

• The Siemens HED41B060 is specifically designed for use in commercial and industrial settings where high reliability and performance are paramount. Its high breaking capacity makes it suitable for critical applications requiring robust protection against electrical faults. Ideal for use in distribution panels, motor control centers, and branch circuit protection, this breaker is a trusted component in ensuring the safety and efficiency of electrical systems.
