HEB3B110B - 110Amp Circuit Breaker

HEB3B110B - 110Amp Circuit Breaker

Introducing the Siemens HEB3B110B Circuit Breaker, a robust solution designed for low voltage panelboard applications. This circuit breaker is built with a thermal-magnetic trip unit, ensuring reliable protection against overcurrent situations.

Key Features and Benefits:

• High Breaking Capacity: The HEB3B110B offers exceptional breaking capacity, rated at 25kAIC at 600Y/347V and 65kAIC at 480V. This makes it suitable for demanding electrical environments, ensuring safety and reliability.
• Thermal-Magnetic Trip Unit: Provides dual protection by combining thermal protection for overload conditions and magnetic protection for short-circuit events, enhancing the safety of your electrical systems.
• Load Side Lugs Only: Equipped with TA1EG10 load side lugs, supporting a wire range of 8 - 1/0 AWG (copper/aluminum), facilitating straightforward installation and maintenance.
• Compact Dimensions: Measuring 3 x 5.5 x 3 inches, this circuit breaker is designed to fit seamlessly into existing panelboard setups, making it an ideal choice for replacements and upgrades.

Technical Specifications:

• Frame Type: EG Frame
• Rated Current: 110A
• Poles: 3
• Breaking Capacity: 25kAIC at 600Y/347V, 65kAIC at 480V
• Wire Range: 8 - 1/0 AWG (CU/AL)
• Dimensions: 3 x 5.5 x 3 inches
• Weight: 1.257 lbs

Material Compliance and Certifications:

• Compliance: The HEB3B110B complies with UL standards, ensuring it meets the stringent safety and performance requirements expected in the industry.

Suitability:

• Ideal for use in low voltage panelboards where high breaking capacity is essential, the HEB3B110B is perfect for commercial and industrial applications. Its robust construction and reliable performance make it a valuable component for ensuring electrical system safety and efficiency.
