HEB3B080B - 80Amp Circuit Breaker

HEB3B080B - 80Amp Circuit Breaker

Introducing the Siemens HEB3B080B Circuit Breaker, a high-performance solution engineered for demanding electrical applications. This low-voltage panelboard mount breaker is part of the EG Frame series, featuring a robust thermal-magnetic trip unit designed to deliver reliable protection. UL listed and recognized for its high breaking capacity, this circuit breaker is an optimal choice for ensuring the safety and efficiency of your electrical systems.

Key Features and Benefits:

• High Breaking Capacity: With a breaking capacity of 25KAIC at 600Y/347V and 65KAIC at 480V, the HEB3B080B offers superior protection against electrical faults.
• Thermal-Magnetic Trip Unit: Provides consistent and reliable trip characteristics, safeguarding your circuits from overloads and short circuits.
• Load Side Lugs Only: Equipped with TA1EG10 load side lugs, supporting a wire range of 8 - 1/0 AWG (CU/AL), ensuring easy and secure connections.
• Compact Design: Dimensions of 3 x 5.5 x 3 inches allow for versatile mounting options and efficient use of space in panelboards.

Technical Specifications:

• Amperage Rating: 80A
• Poles: 3
• Voltage Rating: Suitable for systems operating at 600Y/347V and 480V
• Interrupting Rating: 25KAIC at 600Y/347V, 65KAIC at 480V
• Wire Range: 8 - 1/0 AWG (CU/AL)
• Dimensions: 3 inches (W) x 5.5 inches (H) x 3 inches (D)
• Net Weight: 2.557 lbs

Material Compliance and Certifications:

• UL Listed: Ensures compliance with stringent safety standards.
• RoHS Compliance: Meets environmental and safety standards for hazardous materials (specific compliance details may vary, confirm with manufacturer).

Suitability:

• Ideal for commercial and industrial applications, the Siemens HEB3B080B Circuit Breaker is designed for use in panelboards requiring robust electrical protection and reliable performance. Whether for new installations or upgrades, this breaker ensures your electrical systems operate safely and efficiently, minimizing downtime and maintenance costs.
