HEB3B060B - 60Amp Circuit Breaker

HEB3B060B - 60Amp Circuit Breaker

The Siemens HEB3B060B is a 60 Amp, 3-pole molded case circuit breaker for compatible HEB (EG Frame) low-voltage panelboard installations. When replacing a breaker in an existing system, the details matter. The frame type, number of poles, amp rating, voltage rating, and terminal configuration all need to match the equipment already in place. This model includes a thermal-magnetic trip unit and load-side lugs (TA1EG10) for applications requiring the HEB frame design.

Key Features and Benefits

• Siemens HEB (EG Frame) molded case circuit breaker
• 60 Amp current rating
• 3-pole configuration for three-phase applications
• Thermal-magnetic trip unit
• 480 VAC rating
• Load-side lugs (TA1EG10)
• Accepts 8 AWG to 1/0 AWG copper or aluminum conductors

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: HEB3B060B

• Product Type: Molded Case Circuit Breaker

• Frame: HEB (EG Frame)

• Poles: 3

• Current Rating: 60 Amps

• Voltage Rating: 480 VAC

• Trip Unit: Thermal-Magnetic

• Interrupting Rating:65kAIC @ 480 VAC
  25kAIC @ 600Y/347 VAC
• Terminal Configuration: Load-side lugs (TA1EG10)

• Wire Range: 8 AWG to 1/0 AWG Copper/Aluminum

• Dimensions: 3" W × 5.5" H × 3" D

• Weight: 2.513 lb


Material Compliance and Certifications

• UL Listed
• Compatible with copper and aluminum conductors
• ECCN: EAR99
• WEEE Category 5


Where It Works Best

The Siemens HEB3B060B is commonly used in commercial buildings, industrial facilities, and institutional electrical systems that rely on compatible HEB (EG Frame) panelboards.
