HEB3B030B - 30Amp Circuit Breaker

HEB3B030B - 30Amp Circuit Breaker

The Siemens HEB3B030B circuit breaker is a robust and reliable component, designed for low voltage panelboard mounting. Engineered with a thermal-magnetic trip unit, this circuit breaker ensures optimal protection against overloads and short circuits, making it an essential addition to any electrical distribution system.

Key Features and Benefits:

• High Breaking Capacity: The HEB3B030B boasts impressive breaking capacities, ensuring reliable interruption of fault currents at 25kAIC at 600Y/347V and 65kAIC at 480V.
• Thermal-Magnetic Trip Unit: Provides precise protection by combining both thermal and magnetic tripping mechanisms, safeguarding against both overloads and short circuits.
• Load Side Lugs: Equipped with load side lugs (TA1EG10), facilitating easy and secure connections.
• Durable Construction: Built to withstand demanding environments, ensuring long-term reliability and performance.
• Compact Design: With dimensions of 3 x 5.5 x 3 inches, it offers a compact solution for space-constrained applications.

Technical Specifications:

• Amperage: 30A
• Poles: 3
• Voltage Rating: 600Y/347V (25kAIC) and 480V (65kAIC)
• Trip Unit: Thermal-Magnetic
• Frame Type: HEB
• UL Listing: Yes
• Dimensions: 3 x 5.5 x 3 inches (W x H x D)
• Wire Range: 8 - 1/0 AWG (Copper/Aluminum)
• Net Weight: 2.557 lbs
• Country of Origin: Dominican Republic

Material Compliance and Certifications:

• UL Listed: Ensures compliance with rigorous safety standards, providing peace of mind and assurance of quality.

Suitability:

• The Siemens HEB3B030B circuit breaker is ideal for a variety of applications, including commercial and industrial settings. It is specifically designed for use in low voltage panelboards and is well-suited for environments where high fault currents are a concern. Its robust design and high breaking capacity make it a reliable choice for protecting electrical circuits and ensuring operational safety.
