HEB3B015B - 15Amp Circuit Breaker

HEB3B015B - 15Amp Circuit Breaker

The Siemens HEB3B015B is a 15 Amp, 3-pole molded case circuit breaker used in compatible HEB (EG) frame low-voltage panelboards. When you're replacing a breaker in an existing system, matching the original specifications is what matters most. The frame type, number of poles, amp rating, voltage rating, and lug arrangement all need to match the existing installation. This model uses a thermal-magnetic trip unit to help protect your circuits from overloads and short circuits while keeping the original HEB frame requirements in place.

Key Features and Benefits

• Siemens HEB (EG Frame) molded case circuit breaker
• 15 Amp current rating
• 3-pole configuration
• Thermal-magnetic trip protection
• Rated for 480 VAC applications
• Load-side lugs (TA1EG10)
• Accepts 8 AWG to 1/0 AWG copper or aluminum conductors
• Matches the form, fit, and function of compatible HEB frame installations

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: HEB3B015B

• Product Type: Molded Case Circuit Breaker

• Frame: HEB (EG Frame)

• Poles: 3

• Current Rating: 15 Amps

• Voltage Rating: 480 VAC

• Trip Unit: Thermal-Magnetic

• Interrupting Rating:65kAIC @ 480 VAC
  25kAIC @ 600Y/347 VAC
• Terminal Configuration: Load-side lugs (TA1EG10)

• Wire Range: 8 AWG to 1/0 AWG Copper/Aluminum

• Dimensions: 3" W × 5.5" H × 3" D

• Weight: 2.513 lb

• Country of Origin: Dominican Republic


Material Compliance and Certifications

• UL Listed
• Compatible with copper and aluminum conductors
• ECCN: EAR99
• Commodity Code: 8536200040
• WEEE Category 5
• Not classified as dangerous goods


Where It Works Best

The Siemens HEB3B015B is commonly used in commercial buildings, industrial facilities, and institutional electrical systems that use HEB (EG) frame panelboards. It is suited for maintenance and replacement projects where the existing breaker needs to match the original equipment specifications.
