HEB2B030B - 30Amp Circuit Breaker

HEB2B030B - 30Amp Circuit Breaker

The Siemens HEB2B030B Circuit Breaker is a highly reliable and efficient component designed for low voltage panelboard applications. Featuring an EG frame with a thermal-magnetic trip unit, this circuit breaker ensures optimal protection and performance in both residential and commercial settings.

Key Features and Benefits:

• High Breaking Capacity: The HEB frame provides a breaking capacity of 25kAIC at 600Y/347V and 65kAIC at 480V, making it suitable for demanding applications.
• Thermal-Magnetic Trip Unit: This feature ensures precise and reliable protection by responding to both overloads and short circuits.
• Compact Design: With dimensions of 2 x 5.5 x 3 inches (W x H x D), this circuit breaker is compact yet powerful, fitting seamlessly into various panelboard configurations.
• Load Side Lugs Only: Equipped with TA1EG10 load side lugs, accommodating wire ranges from 8 to 1/0 AWG (CU/AL).

Technical Specifications:

• Current Rating: 30A
• Poles: 2
• Breaking Capacity: 25kAIC at 600Y/347V, 65kAIC at 480V
• Dimensions: 2 x 5.5 x 3 inches
• Wire Range: 8 - 1/0 AWG (CU/AL)
• Weight: 1.962 lb

Material Compliance and Certifications:

• UL Listed: Meets the UL safety standards for reliable performance and safety.
• WEEE Take-Back Obligation: Yes, in compliance with 2012/19/EU.

Suitability:

• The Siemens HEB2B030B Circuit Breaker is ideal for a range of applications, including residential, commercial, and industrial settings. Its high breaking capacity and thermal-magnetic trip unit make it particularly suitable for environments that demand high reliability and safety. Contractors and electricians will appreciate its ease of installation and robust performance, ensuring protection and efficiency in electrical systems.
