HE3B030 - 30Amp Circuit Breaker

HE3B030 - 30Amp Circuit Breaker

The HE3B030 is a 3-pole, 30-amp molded case circuit breaker used to provide overcurrent protection in commercial and industrial electrical distribution systems. Manufactured as an HE3 Type breaker, it is intended as a form, fit, and functional replacement for compatible equipment already in service.

Whether you're replacing a failed breaker during maintenance or keeping an existing system operating as intended, the HE3B030 delivers the ratings and physical configuration needed for compatible applications.

Key Features and Benefits

• 30 Amp current rating
• Three-pole configuration for three-phase electrical systems
• HE3 Type molded case circuit breaker
• Form, fit, and functional replacement for compatible equipment
• Rated for operation in 40°C ambient conditions
• Compact molded case design for installations designed around the HE3 frame
• Built to provide long service life in compatible electrical systems


Technical Specifications

• Part Number: HE3B030

• Type: HE3

• Circuit Breaker Style: Molded Case Circuit Breaker

• Poles: 3

• Current Rating: 30 Amps

• Interrupting Capacity:18kA @ 600VAC
  25kA @ 480VAC
  65kA @ 240VAC
• Operating Temperature: 40°C

• Dimensions: 4.50" W × 6.00" H × 3.63" D

• Approximate Shipping Weight: 7.00 lbs.


Material Compliance and Certifications

• Molded case circuit breaker construction
• Manufactured for use in compatible electrical distribution equipment
• Designed to match the electrical ratings and physical dimensions associated with the HE3 Type platform


Where It Works Best

The HE3B030 is commonly used in commercial buildings, industrial facilities, manufacturing plants, and other electrical distribution systems that utilize compatible HE3 Type circuit breakers. It can be found in switchboards, panelboards, motor control equipment, and similar power distribution assemblies where a 30-amp, three-pole breaker with these interrupting ratings is required.
