HE3B015 - 15Amp Circuit Breaker

HE3B015 - 15Amp Circuit Breaker

The HE3B015 is a 15 Amp, 3-pole HE3 molded case circuit breaker designed for use in compatible commercial and industrial electrical distribution equipment. When an existing breaker needs to be replaced, matching the original specifications is often the most important part of the job.

Whether you're replacing a failed breaker during routine maintenance or keeping older equipment in service, verifying the part number, amperage, pole count, physical dimensions, and interrupting rating before installation is essential.

Key Features and Benefits

• 15 Amp molded case circuit breaker
• Three-pole configuration
• HE3 frame type
• Intended for compatible legacy electrical systems
• Designed for form, fit, and functional replacement
• Rated for applications up to 600VAC
• 40°C ambient temperature rating
• Compact molded case construction
• Built for long service life when properly applied


Technical Specifications

• Part Number: HE3B015

• Product Type: Molded Case Circuit Breaker

• Frame Type: HE3

• Current Rating: 15 Amps

• Poles: 3

• Interrupting Rating:65kA at 240VAC
  25kA at 480VAC
  18kA at 600VAC
• Temperature Rating: 40°C

• Dimensions: 4.50 in. W × 6.00 in. H × 3.63 in. D

• Width: 4.50 in.

• Height: 6.00 in.

• Depth: 3.63 in.

• Approximate Weight: 7.0 lb


Material Compliance and Certifications

Certification and compliance information was not included in the available product specifications. Before installation, verify any required listings or approvals by reviewing the breaker nameplate or the documentation for the equipment in which it will be installed.

Installation should always be completed by qualified personnel and in accordance with the National Electrical Code, local regulations, and manufacturer recommendations.

Where It Works Best

• Commercial electrical distribution equipment
• Industrial electrical systems
• Three-phase branch circuits
• Manufacturing facilities
• Mechanical equipment panels
• Legacy HE3 breaker installations
• Maintenance and repair projects
• Form, fit, and functional replacement applications
