HB1B030 - 30Amp Circuit Breaker

HB1B030 - 30Amp Circuit Breaker

Finding the right replacement for your breaker starts with matching the original specifications, and the HB1B030 is built for exactly that purpose. Its bolt-on design provides a secure connection in equipment designed for BQ breakers, while the included load-side lugs help make installation a little easier.

Key Features and Benefits

• 30 Amp continuous current rating
• Single-pole breaker for 120V AC circuits
• Bolt-on BQ design for compatible panelboards
• Molded case construction for branch circuit protection
• Load-side lugs included
• Form, fit, and functional replacement for compatible equipment
• Built to last for long-term use in existing electrical systems


Technical Specifications

• Catalog Number: HB1B030

• Manufacturer Part Number (MFN): HB1B030

• Manufacturer: Siemens

• Product Family: Branch Circuit Breakers

• Product Type: Molded Case Circuit Breaker

• Breaker Design: BQ

• Poles: 1

• Amperage Rating: 30 Amps

• Voltage Rating: 120V AC

• Interrupting Capacity: 65kA AIC

• Connection Type: Bolt-On

• Application: Branch circuit protection and electrical distribution

• Load-Side Lugs: Included

• Dimensions: 4 in. D × 3 in. W × 1 in. H

• Packaging Dimensions: 3.937 in. × 2.756 in. × 0.787 in.

• Net Weight: 0.353 lb.

• UPC: 783643111134

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 Listed
• Manufactured for applications requiring a UL 489 molded case circuit breaker
• REACH information is available from the manufacturer
• RoHS compliance information was not listed in the published specifications
• SCIP information was not listed in the published specifications
• Install in accordance with the National Electrical Code (NEC), local electrical codes, and the equipment manufacturer's instructions.


Where It Works Best

• Compatible BQ bolt-on panelboards
• Residential electrical distribution systems
• Commercial electrical panels
• Industrial electrical distribution equipment
• General-purpose 120V branch circuits
• Lighting and equipment circuits requiring a 30 Amp breaker
• Maintenance and repair projects where a compatible 30 Amp, single-pole BQ bolt-on circuit breaker is required
