HAGF250 - 50Amp Circuit Breaker

HAGF250 - 50Amp Circuit Breaker

The HAGF250 Circuit Breaker by Challenger is a high-performance solution designed to provide reliable ground fault protection for both residential and commercial applications. With a robust 50-ampere rating and operating at 120/240 volts, this two-pole circuit breaker ensures comprehensive protection against electrical faults. Its impressive interrupting capacity of 10 kAIC makes it an essential component for maintaining electrical safety and reliability.

Key Features and Benefits:

• Superior Ground Fault Protection: The integrated ground fault circuit interrupter (GFI) promptly detects and interrupts ground faults, significantly reducing the risk of electrical shocks and enhancing overall safety.
• High Interrupting Capacity: With a 10 kAIC rating, the HAGF250 can manage substantial electrical faults, ensuring durability and reliability in high-demand environments.
• Two-Pole Configuration: Provides superior circuit protection for both legs of the electrical circuit, making it ideal for safeguarding larger appliances and systems.

Technical Specifications:

• Amperage Rating: 50 A
• Voltage Rating: 120/240 V
• Interrupting Capacity: 10 kAIC
• Type: HAGF
• Protection Sensitivity: 5 mA
• Dimensions: Length 4.5 in, Width 2 in, Height 2.75 in
• Weight: 0.7 lbs
• Poles: Two-pole
• Wire Size: #14-4 AWG

Material Compliance and Certifications:

• Certifications: The HAGF250 circuit breaker meets the highest industry standards, ensuring optimal performance and safety. It is certified by UL 943 and UL 489, and meets the Federal Specification Classification WC375.

Suitability:

• The HAGF250 Circuit Breaker is ideal for a wide range of applications, including residential homes, commercial buildings, and industrial facilities.
• Its ground fault protection is particularly beneficial in areas where electrical safety is paramount, such as kitchens, bathrooms, and outdoor spaces.
• Whether you are upgrading an existing system or installing a new one, the HAGF250 provides the dependable protection you need.

Discover more about the HAGF250 Circuit Breaker and how it can enhance the safety and reliability of your electrical system.
