HAGF240 - 40Amp Circuit Breaker

HAGF240 - 40Amp Circuit Breaker

The HAGF240 Circuit Breaker by Challenger is designed to provide superior ground fault protection, ensuring the safety and reliability of your electrical systems in both residential and commercial environments. This two-pole circuit breaker boasts a robust 40-ampere rating and operates at 120/240 volts, delivering comprehensive protection against electrical faults. With a high interrupting capacity of 10 kAIC, the HAGF240 is engineered to handle significant electrical loads, making it a crucial component for maintaining electrical safety.

Key Features and Benefits:

• High Interrupting Capacity: With a 10 kAIC rating, this circuit breaker can manage substantial electrical faults, ensuring durability and reliability in high-demand environments.
• Two-Pole Configuration: Provides superior protection for both legs of the electrical circuit, making it ideal for safeguarding larger appliances and systems.

Technical Specifications:

• Amperage Rating: 40 A
• Voltage Rating: 120/240 V
• Interrupting Capacity: 10 kAIC
• Type: HAGF
• Protection Sensitivity: 5 mA
• Dimensions: Length 4.5 in, Width 2 in, Height 2.75 in
• Weight: 0.7 lbs
• Poles: Two-pole
• Wire Size: #14-4 AWG

Material Compliance and Certifications:

• Compliance: The HAGF240 circuit breaker meets the highest industry standards, ensuring optimal performance and safety. It is certified by UL 943 and UL 489, and meets the Federal Specification Classification WC375. Backed by a 10-year warranty, this breaker exemplifies Challenger's commitment to quality and reliability.

Suitability:

• The HAGF240 Circuit Breaker is ideal for a wide range of applications, including residential homes, commercial buildings, and industrial facilities. Its ground fault protection is particularly beneficial in areas where electrical safety is paramount, such as kitchens, bathrooms, and outdoor spaces. Whether you are upgrading an existing system or installing a new one, the HAGF240 provides the dependable protection you need.

Discover more about the HAGF240 Circuit Breaker and how it can enhance the safety and reliability of your electrical system.
