HAGF230 - 30Amp Circuit Breaker

HAGF230 - 30Amp Circuit Breaker

The HAGF230 Circuit Breaker by Challenger is designed to deliver superior ground fault protection, ensuring the safety and reliability of your electrical systems in residential and commercial settings. This two-pole circuit breaker features a robust 30-ampere rating and operates at 120/240 volts, providing comprehensive protection against electrical faults. With an impressive interrupting capacity of 10 kAIC, the HAGF230 is engineered to handle substantial electrical loads, making it an essential component for maintaining electrical safety.

Key Features and Benefits:

• High Interrupting Capacity: With a 10 kAIC rating, this circuit breaker can manage significant electrical faults, ensuring durability and reliability even in high-demand environments.
• Two-Pole Configuration: Provides superior circuit protection for both legs of the electrical circuit, making it ideal for safeguarding larger appliances and systems.

Technical Specifications:

• Amperage Rating: 30 A
• Voltage Rating: 120/240 V
• Interrupting Capacity: 10 kAIC
• Type: HAGF
• Protection Sensitivity: 5 mA
• Dimensions: Length 4.5 in, Width 2 in, Height 2.75 in
• Weight: 0.7 lbs
• Poles: Two-pole
• Wire Size: #14-4 AWG

Material Compliance and Certifications:

• Compliance: The HAGF230 circuit breaker meets the highest industry standards, ensuring optimal performance and safety. It is certified by UL 943 and UL 489, and meets the Federal Specification Classification WC375. Backed by a 10-year warranty, this breaker exemplifies Challenger's commitment to quality and reliability.

Suitability:

• The HAGF230 Circuit Breaker is ideal for a wide range of applications, including residential homes, commercial buildings, and industrial facilities. Its ground fault protection is particularly beneficial in areas where electrical safety is paramount, such as kitchens, bathrooms, and outdoor spaces. Whether you are upgrading an existing system or installing a new one, the HAGF230 provides the dependable protection you need.
