GHC3050 - 50Amp Circuit Breaker

GHC3050 - 50Amp Circuit Breaker

When you're replacing a circuit breaker in an existing electrical system, the best fit is usually the one that matches what is already installed. The GHC3050 Eaton Series C molded case circuit breaker is a 50 Amp, 3-pole breaker for Eaton Series C G-Frame equipment where the original breaker configuration, ratings, and mounting requirements need to stay the same.

Key Features and Benefits

• 50 Amp, 3-pole molded case circuit breaker
• Eaton Series C G-Frame complete breaker design
• Thermal magnetic protection for overload and short-circuit conditions
• T186 trip unit configuration
• Rated for 480Y/277VAC and 125/250VDC applications
• Three-pole design for multi-conductor circuit protection
• Complete breaker configuration for Series C equipment
• Suitable for replacement and electrical maintenance work
• Helps keep existing equipment specifications unchanged
• Built for continued use in properly maintained systems

Technical Specifications

• Catalog Number: GHC3050

• Product Type: Molded Case Circuit Breaker

• Manufacturer Series: Eaton Series C

• Circuit Breaker Type: GHC

• Frame Type: G-Frame

• Breaker Design: Complete Breaker

• Amperage Rating: 50 Amps

• Number of Poles: 3

• Trip Type: T186 Thermal Magnetic

• Voltage Rating: 480Y/277VAC, 125/250VDC

• Frequency Rating: 50/60Hz

• Interrupt Rating:
  65kAIC at 240VAC
  14kAIC at 480Y/277VAC

• Product Length/Depth: 2.63 inches

• Product Height: 4.88 inches

• Product Width: 3 inches

• Product Weight: 1.7 lbs.


Material Compliance and Certifications

The GHC3050 Eaton Series C molded case circuit breaker is UL Listed and manufactured for use in electrical equipment requiring a properly matched molded case breaker. It follows the specifications associated with the Eaton Series C G-Frame product family.

Where It Works Best

• Eaton Series C electrical equipment
• G-Frame molded case breaker applications
• Commercial and industrial electrical systems
• Three-phase circuit protection applications
• Existing equipment requiring a 50 Amp, 3-pole breaker
• Electrical maintenance and replacement projects
• Systems requiring thermal magnetic overload and short-circuit protection
• Applications within the specified AC and DC voltage ratings
