GHB3070 - 70Amp Circuit Breaker

GHB3070 - 70Amp Circuit Breaker

Introducing the Eaton GHB3070, a top-tier solution from Eaton's Series C molded case circuit breakers. This three-pole, 70Amp breaker is engineered for superior performance in demanding electrical environments. With fixed thermal and magnetic trip mechanisms, this breaker guarantees precise and dependable operation, safeguarding your electrical systems from overloads and short circuits.

Key Features and Benefits:

• High Interrupting Capacity: With a rating of 14 kAIC at 480Y/277 Vac and 65 kAIC at 240 Vac, the GHB3070 provides robust protection against electrical faults, minimizing the risk of damage to connected equipment.
• Fixed Thermal and Magnetic Trip: Ensures consistent and accurate protection, enhancing the reliability of your electrical systems.
• Versatile Voltage Rating: Compatible with both AC (480Y/277 Vac) and DC (125/250 Vdc) systems, offering flexibility for a wide range of applications.

Technical Specifications:

• Amperage Rating: 70Amp
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Frequency: 50/60 Hz
• Interrupting Capacity: 14 kAIC at 480Y/277 Vac, 65 kAIC at 240 Vac
• Trip Type: Fixed Thermal, Fixed Magnetic
• Poles: Three-pole
• Dimensions: 2.63 in (Length) x 4 in (Height) x 3 in (Width)
• Weight: 1.7 lbs

Material Compliance and Certifications:

• Compliance: The Eaton GHB3070 complies with Federal Specifications Classification WC375B and is UL Listed, ensuring it meets stringent safety and performance standards. This certification underscores its reliability and suitability for use in critical applications, providing assurance that it adheres to high-quality manufacturing processes and material standards.

Suitability:

• Ideal for a variety of applications, the GHB3070 is suitable for use in commercial buildings, industrial facilities, and critical infrastructure projects. Its high interrupting capacity and reliable trip mechanisms make it perfect for protecting sensitive equipment and ensuring the safety of electrical installations. Whether used in motor protection, power distribution, or panel boards, the Eaton GHB3080 delivers unparalleled performance and peace of mind.
