GHB3060 - 60Amp Circuit Breaker

GHB3060 - 60Amp Circuit Breaker

The Eaton GHB3060 is a 60-amp, 3-pole molded case circuit breaker designed for commercial and industrial electrical distribution systems. Rated for 480Y/277V AC and 125/250V DC, it is commonly used in panels, switchgear, and equipment where dependable circuit protection is required. The breaker utilizes a T186 thermal-magnetic trip unit, which responds to overloads and short circuits to help protect your wiring and connected equipment from damage.

Built on Eaton's Series C G-frame platform, the GHB3060 is often selected for applications where maintaining the original breaker specifications is important. Its compact footprint allows it to fit into many existing electrical systems, making it a practical choice for maintenance, repair, and replacement projects. With interrupting ratings of 14kAIC at 480Y/277V AC and 65kAIC at 240V AC, it can be applied in systems with higher available fault currents while meeting the requirements of many commercial and industrial installations.

Built to last, the GHB3060 continues to be used in facilities where matching the original amperage, voltage rating, frame size, and interrupting capacity is essential to keeping your equipment operating as intended.

Key Features and Benefits

• 60-amp current rating
• 3-pole molded case circuit breaker
• Rated for 480Y/277V AC and 125/250V DC applications
• T186 thermal-magnetic trip unit
• 14kAIC interrupting rating at 480Y/277V AC
• 65kAIC interrupting rating at 240V AC
• Series C G-frame construction
• Compact footprint for panel integration
• Suitable for commercial and industrial electrical systems

Technical Specifications

• Catalog Number: GHB3060
• Manufacturer: Eaton
• Series: Series C
• Frame Type: G Frame
• Product Type: Molded Case Circuit Breaker
• Amperage Rating: 60 Amps
• Poles: 3
• Voltage Rating: 480Y/277V AC; 125/250V DC
• Trip Unit: T186 Thermal-Magnetic
• Interrupting Rating: 14kAIC @ 480Y/277V AC; 65kAIC @ 240V AC
• Frequency Rating: 50/60 Hz
• Length: 2.63 in.
• Width: 3 in.
• Height: 4 in.
• Weight: 1.7 lb.

Material Compliance and Certifications

• UL Listed
• Compliant with Federal Specification W-C375B
• Manufactured for commercial and industrial electrical applications
• Designed for installation in accordance with applicable electrical codes and standards

Where It Works Best

• Commercial electrical distribution panels
• Industrial facilities
• Switchgear assemblies
• Control panels
• Branch circuit protection
• Feeder circuit protection
• Motor and equipment protection
• Maintenance and repair projects
• Retrofit applications
• Systems requiring a 60A, 3-pole molded case circuit breaker

When you're replacing an existing breaker, matching the original specifications is often the most important consideration.
