GHB3040 - 40Amp Circuit Breaker

GHB3040 - 40Amp Circuit Breaker

The Eaton GHB3040 Series C Complete Molded Case Circuit Breaker delivers industrial-grade performance, uncompromising reliability, and exceptional safety for commercial and light industrial electrical systems. Designed with a robust G-frame and fixed thermal-magnetic trip mechanism, this breaker is ideal for protecting circuits from overloads and short circuits in demanding power distribution applications. Its three-pole configuration ensures balanced load protection for 480Y/277 VAC and 125/250 VDC systems, supporting operations across a wide range of frequencies (50/60 Hz).

Key Features and Benefits

• Heavy-Duty Protection: Engineered for 14 kAIC interrupt capacity at 480Y/277 VAC and an impressive 65 kAIC at 240 VAC, ensuring resilience in high fault-current environments.
• Fixed Thermal-Magnetic Trip: Delivers consistent performance, with fixed settings optimized for 40-amp applications.
• Versatile Voltage Support: Handles both AC and DC loads (480Y/277 VAC and 125/250 VDC) with reliability.
• Compact & Durable: Measures only 4 inches in height and 3 inches in width, making it ideal for space-constrained installations without compromising strength.
• Trusted Brand Assurance: Backed by Eaton’s Selling Policy 25-000 with a one-year warranty from installation or 18 months from shipment, whichever comes first.


Technical Specifications

• Amperage Rating: 40 A

• Voltage Rating: 480Y/277 VAC, 125/250 VDC

• Interrupt Rating: 14 kAIC at 480Y/277 VAC; 65 kAIC at 240 VAC

• Frequency Rating: 50/60 Hz

• Trip Type: T186 (Fixed Thermal, Fixed Magnetic)

• Number of Poles: Three-pole

• Frame Type: G-frame

• Series: Series C

• Breaker Type: GHB

• Dimensions: 2.63 in (Depth) x 4 in (Height) x 3 in (Width)

• Weight: 1.75 lb


Material Compliance and Certifications

• Certifications: UL Listed
• Compliances: Federal Specifications Classification W-C375B
• Warranty: 1 year from installation or 18 months from shipment (Eaton Selling Policy 25-000)


Suitability

• Perfect for commercial facilities, manufacturing environments, and panel builders, the GHB3040 is your go-to molded case circuit breaker for safeguarding three-phase systems with confidence. Its compatibility with both alternating and direct current systems broadens its use across complex electrical installations, making it a versatile and trusted component in any power distribution infrastructure.
