GHB3020 - 20 Amp Circuit Breaker
GHB3020 - 20 Amp Circuit Breaker
Couldn't load pickup availability
GHB3020 - 20 Amp Circuit Breaker
The Eaton GHB3020 is a 20 Amp, 3-pole molded case breaker built for commercial and industrial electrical systems. Part of Eaton's Series C G-Frame line, it uses a T186 thermal-magnetic trip unit to protect your circuits from overloads and short circuits. Rated for 480Y/277V AC and 125/250V DC, it fits distribution panels, motor control centers, and switchgear assemblies where space is limited and reliable protection is required. Its compact G-Frame design helps ensure a clean, efficient installation, and the high interrupting ratings—14 kAIC at 480Y/277V AC and 65 kAIC at 240V AC—handle fault currents safely in demanding environments.
Key Features and Benefits
- 20 Amp current rating
- 3-pole configuration for three-phase circuits
- Series C G-Frame molded case design
- T186 thermal-magnetic trip unit
- Rated for 480Y/277V AC and 125/250V DC
- 14 kAIC interrupting rating at 480Y/277V AC
- 65 kAIC interrupting rating at 240V AC
- Compact design for easier panel integration
- Complete breaker for maintenance, retrofit, or replacement
- Suitable for commercial and industrial systems
Technical Specifications
-
Manufacturer: Eaton
-
Catalog Number: GHB3020
-
UPC: 786679911266
-
Product Type: Molded Case Circuit Breaker
-
Series: Series C
-
Breaker Type: GHB
-
Frame Type: G Frame
-
Amperage Rating: 20A
-
Poles: 3
-
Voltage Rating: 480Y/277V AC; 125/250V DC
-
Trip Unit: T186 Thermal-Magnetic
-
Frequency Rating: 50/60 Hz
-
Interrupting Rating: 14 kAIC @ 480Y/277V AC; 65 kAIC @ 240V AC
-
Dimensions:
- Length: 2.63 in.
- Width: 3 in.
- Height: 4 in.
-
Weight: 1.75 lb
Material Compliance and Certifications
- UL Listed
- Complies with Federal Specification W-C375B
- Meets Eaton quality standards for commercial and industrial use
Where It Works Best
- Commercial and industrial distribution panels
- Motor control centers and switchgear
- Branch and feeder circuits
- Control panels and electrical systems
- Maintenance, retrofit, or replacement projects
