GHB1020 - 20Amp Circuit Breaker

GHB1020 - 20Amp Circuit Breaker

The Eaton GHB1020 is a robust and reliable single-pole circuit breaker designed to ensure the safety and efficiency of electrical systems. Part of the esteemed Series C molded case circuit breakers, the GHB1020 model is engineered to meet the rigorous demands of both residential and commercial applications. With a fixed thermal and fixed magnetic trip type, this breaker guarantees precise and dependable protection against overloads and short circuits. Its compact size makes it an ideal choice for space-constrained installations, ensuring seamless integration into existing systems.

Key Features and Benefits:

• High Interrupting Capacity: Rated at 14 kAIC at 277 Vac, the GHB1020 provides exceptional interrupting performance, making it suitable for a wide range of applications.
• Versatile Voltage Ratings: Supports both AC and DC applications with voltage ratings of 277 Vac and 125 Vdc, respectively.
• Reliable Protection: Features a fixed thermal and fixed magnetic trip mechanism to ensure consistent and accurate response to electrical faults.

Technical Specifications:

• Amperage Rating: 20Amp
• Voltage Rating: 277 Vac, 125 Vdc
• Interrupt Rating: 14 kAIC at 277 Vac
• Frequency Rating: 50/60 Hz
• Trip Type: Fixed Thermal, Fixed Magnetic
• Number of Poles: Single-Pole
• Frame Type: G-Frame

Material Compliance and Certifications:

• UL Listed: Ensures the product meets stringent safety standards.
• Federal Specifications Classification WC375B: Complies with federal requirements for molded case circuit breakers.

Suitability:

• The Eaton GHB1020 is an excellent choice for contractors and electricians seeking a reliable and efficient circuit breaker for their projects. Its high interrupting capacity and versatile voltage ratings make it ideal for protecting electrical systems in residential, commercial, and industrial settings. Whether it's for new installations or upgrades, the GHB1020 ensures optimal performance and safety.
