GFCB240 - 40 Amp Circuit Breaker

GFCB240 - 40 Amp Circuit Breaker

The GFCB240 is a 40 Amp, 2-pole plug-on circuit breaker used in electrical panels that accept the GFCB series breaker style. It provides thermal-magnetic protection for overload and short-circuit conditions and includes a common trip design so both poles operate together when the breaker trips. The breaker is also HACR rated, making it suitable for heating, air conditioning, and refrigeration applications.

When you're replacing a breaker, getting the specifications right is the important part. The amperage, voltage rating, pole count, and mounting style all need to match the panel and the circuit being serviced. The GFCB240 plug-on design is made for compatible panels, while the two-pole configuration allows it to be used on circuits that require protection across both legs of a 120/240V supply.

Key Features and Benefits

• 40 Amp, 2-pole circuit breaker
• Plug-on connection for GFCB series panels
• HACR rated for heating, air conditioning, and refrigeration applications
• Common trip operation across both poles
• Thermal-magnetic protection for overloads and short circuits
• Designed for two-pole branch circuit applications
• Suitable for HVAC and equipment circuits
• Compact design for compatible panel installations
• Built to last for maintenance and replacement work


Technical Specifications

• Catalog Number: GFCB240

• Product Type: Plug-On Circuit Breaker

• Series / Type: GFCB

• Amperage Rating: 40 Amps

• Number of Poles: 2

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kAIC at 120/240VAC

• Trip Configuration: Common Trip

• Application Rating: HACR Rated

• Mounting Style: Plug-On

• Height: 3.19 in.

• Width: 2.00 in.

• Depth: 2.50 in.

• Dimensions: 2.00 in. W × 3.19 in. H × 2.50 in. D

• Approximate Shipping Weight: 3.00 lbs.


Material Compliance and Certifications

The GFCB240 is intended for use as a circuit protection component in electrical panels designed for this breaker style. Installation should be completed by qualified electrical personnel following the National Electrical Code (NEC), local electrical requirements, and standard safety practices.

Where It Works Best

• Electrical panels designed for GFCB series plug-on breakers
• Residential electrical systems
• Commercial branch circuits
• HVAC and refrigeration equipment circuits
• Two-pole equipment circuits
• Electrical panel repair and maintenance work
• Breaker replacement projects
• Existing installations requiring a 40 Amp GFCB series breaker
• Applications where matching the existing breaker specifications is important

The GFCB240 40 Amp Plug-On Circuit Breaker is a straightforward replacement when an existing application calls for a 2-pole GFCB series breaker.
