GFCB220 - 20 Amp Circuit Breaker

GFCB220 - 20 Amp Circuit Breaker

The GFCB220 is a 20 Amp, 2-pole plug-on circuit breaker used in electrical panels that accept the GFCB series breaker style. It features thermal-magnetic protection for overload and short-circuit conditions, along with a common trip design and HACR rating for heating, air conditioning, and refrigeration applications.

When you're replacing a breaker, the goal is simple: find the right part for the panel you already have. The amperage rating, voltage rating, pole count, and mounting style all need to match. The GFCB220 plug-on design is made for compatible panels, and the two-pole configuration allows it to be used on circuits that require protection across both legs of a 120/240V supply.

Key Features and Benefits

• 20 Amp, 2-pole circuit breaker
• Plug-on connection for GFCB series panels
• HACR rated for heating, air conditioning, and refrigeration applications
• Common trip operation across both poles
• Thermal-magnetic protection for overloads and short circuits
• Designed for two-pole branch circuit applications
• Suitable for HVAC and equipment circuits
• Compact design for compatible panel installations
• Built to last for maintenance and replacement applications


Technical Specifications

• Catalog Number: GFCB220

• Product Type: Plug-On Circuit Breaker

• Series / Type: GFCB

• Amperage Rating: 20 Amps

• Number of Poles: 2

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kAIC at 120/240VAC

• Trip Configuration: Common Trip

• Application Rating: HACR Rated

• Mounting Style: Plug-On

• Height: 3.19 in.

• Width: 2.00 in.

• Depth: 2.50 in.

• Dimensions: 2.00 in. W × 3.19 in. H × 2.50 in. D

• Approximate Shipping Weight: 3.00 lbs.


Material Compliance and Certifications

The GFCB220 is intended for use as a circuit protection component in electrical panels designed for this breaker style. Installation should be completed by qualified electrical personnel following the National Electrical Code (NEC), local electrical requirements, and standard safety practices.

Where It Works Best

• Electrical panels designed for GFCB series plug-on breakers
• Residential electrical systems
• Commercial branch circuits
• HVAC and refrigeration equipment circuits
• Two-pole equipment circuits
• Electrical panel service and repair work
• Breaker replacement projects
• Existing installations requiring a 20 Amp GFCB series breaker
• Applications where matching the original breaker specifications is important

The GFCB220 20 Amp Plug-On Circuit Breaker is a straightforward replacement when an existing application calls for a 2-pole GFCB series breaker.
