GFB230 - 30 Amp Circuit Breaker

GFB230 - 30 Amp Circuit Breaker

The GFB230 is a 30 Amp, 2-pole plug-on circuit breaker used in electrical panels that accept the GFB series breaker style. It features thermal-magnetic protection to help protect against overloads and short circuits, along with a common trip design and HACR rating for heating, air conditioning, and refrigeration applications.

When you're replacing a breaker, getting the fit and ratings right is what matters. The GFB230 has a plug-on connection style for compatible panels and a two-pole design for circuits that require protection across both legs of a 120/240V system.

Key Features and Benefits

• 30 Amp, 2-pole circuit breaker
• Plug-on connection for compatible electrical panels
• HACR rated for heating, air conditioning, and refrigeration applications
• Common trip design
• Thermal-magnetic protection for overload and short-circuit conditions
• Designed for two-pole branch circuit applications
• Suitable for HVAC and equipment circuits
• Compact design for compatible panel installations
• Built to last for service, maintenance, and replacement applications


Technical Specifications

• Catalog Number: GFB230

• Product Type: Plug-On Circuit Breaker

• Series / Type: GFB

• Amperage Rating: 30 Amps

• Number of Poles: 2

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kAIC at 120/240VAC

• Trip Configuration: Common Trip

• Application Rating: HACR Rated

• Mounting Style: Plug-On

• Height: 3.19 in.

• Width: 2.00 in.

• Depth: 2.50 in.

• Dimensions: 2.00 in. W × 3.19 in. H × 2.50 in. D

• Approximate Shipping Weight: 3.00 lbs.


Material Compliance and Certifications

The GFB230 is intended for use as a circuit protection component in electrical panel applications requiring this breaker style. Installation should be completed by qualified electrical personnel following the National Electrical Code (NEC), local electrical requirements, and standard safety practices.

Where It Works Best

• Electrical panels designed for GFB series plug-on breakers
• Residential branch circuits
• Commercial electrical applications
• HVAC and refrigeration equipment circuits
• Two-pole equipment circuits
• Electrical panel service work
• Breaker replacement projects
• Existing installations requiring a 30 Amp GFB series breaker
• Maintenance applications where matching the existing breaker is important

The GFB230 30 Amp Plug-On Circuit Breaker is a straightforward replacement when an existing application calls for a 2-pole GFB series breaker.
