GFB215 - 15 Amp Circuit Breaker

GFB215 - 15 Amp Circuit Breaker

The GFB215 is a 15 Amp, 2-pole plug-on circuit breaker designed for electrical panels that use the GFB series breaker style. It features thermal-magnetic protection to help protect circuits from overloads and short circuits, along with a common trip design and HACR rating for heating, air conditioning, and refrigeration applications. With a 10kA interrupting rating at 120/240VAC, this breaker is commonly used for two-pole branch circuits where the existing installation calls for these ratings.

Finding the right replacement for your breaker often comes down to matching the details. The amperage, voltage, number of poles, and mounting style all need to line up with the existing panel.

Key Features and Benefits

• 15 Amp, 2-pole circuit breaker
• Plug-on connection for compatible electrical panels
• HACR rated for heating, air conditioning, and refrigeration applications
• Common trip configuration
• Thermal-magnetic protection for overload and short-circuit conditions
• Designed for two-pole branch circuit applications
• Suitable for equipment and HVAC-related circuits
• Compact design for compatible panel installations


Technical Specifications

• Catalog Number: GFB215

• Product Type: Plug-On Circuit Breaker

• Series / Type: GFB

• Amperage Rating: 15 Amps

• Number of Poles: 2

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kAIC at 120/240VAC

• Trip Configuration: Common Trip

• Application Rating: HACR Rated

• Mounting Style: Plug-On

• Height: 3.19 in.

• Width: 2.00 in.

• Depth: 2.50 in.

• Dimensions: 2.00 in. W × 3.19 in. H × 2.50 in. D

• Approximate Shipping Weight: 3.00 lbs.


Material Compliance and Certifications

The GFB215 is intended for use as a circuit protection component in compatible electrical panel applications. Installation should be completed by qualified electrical personnel following the National Electrical Code (NEC), local electrical requirements, and standard safety practices.

Where It Works Best

• Compatible plug-on electrical panels
• Residential electrical systems
• Commercial branch circuits
• HVAC and refrigeration equipment circuits
• Two-pole equipment circuits
• Electrical panel service work
• Breaker replacement projects
• Existing installations requiring a 15 Amp GFB series breaker
• Applications where matching the original breaker specifications is important
