FXD63B080L - 80Amp Circuit Breaker

FXD63B080L - 80Amp Circuit Breaker

Introducing the Siemens FXD63B080L Sentron Molded Case Circuit Breaker, a robust and reliable solution for your electrical protection needs. Engineered with a thermal-magnetic trip unit, this 80A, 3-pole breaker is designed to ensure superior performance and safety in a variety of applications. Whether for industrial, commercial, or residential use, this circuit breaker delivers the durability and efficiency that professionals demand.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Provides reliable protection against overloads and short circuits, ensuring the safety and longevity of your electrical systems.
• High Breaking Capacity: Rated at 22kAIC at 600V and 35kAIC at 480V, it handles high fault currents efficiently.
• Standard 40å¡C Breaker FD Frame: Ensures consistent performance in various environmental conditions.
• Non-Interchangeable Trip: Fixed trip settings for specific protection requirements.
• Line and Load Side Lugs: Equipped with TA1FD350A lugs, supporting a wire range of 6AWG - 350KCM (CU) / 4AWG - 350KCM (AL) for versatile installation options.

Technical Specifications:

• Amperage: 80A
• Poles: 3
• Breaking Capacity: 22kAIC at 600V;åÊ35kAIC at 480V
• Dimensions (W x H x D): 4.5 x 9.5 x 4 inches
• Weight: 8.818 lb
• Frame Type: FD
• Wire Range: 6AWG - 350KCM (CU) / 4AWG - 350KCM (AL)

Material Compliance and Certifications:

• RoHS Compliance: Adheres to the Restriction of Hazardous Substances directive since July 1, 2006, ensuring minimal environmental impact.
• WEEE Directive: Compliant with the Waste Electrical and Electronic Equipment directive (2012/19/EU) for responsible disposal and recycling.
• REACH Compliance: Follows the REACH regulations to inform about the presence of any Substances of Very High Concern (SVHC).

Suitability:

• Industrial: Suitable for manufacturing plants, machinery protection, and heavy-duty electrical installations.
• Commercial: Perfect for office buildings, retail spaces, and public infrastructure requiring reliable circuit protection.
• Residential: Can be used in large residential complexes and buildings to ensure safety and compliance with electrical standards.

Ensure your electrical systems are protected with the Siemens FXD63B080L circuit breaker, a trusted choice for safety, reliability, and performance.
