FXD63A150 - 150Amp Motor Circuit Protector

FXD63A150 - 150Amp Motor Circuit Protector

The Siemens FXD63A150 is a high-quality, low-voltage motor circuit protector, specifically engineered for reliable motor protection in demanding commercial and industrial environments. Featuring a magnetic trip-only unit within a robust FD frame, this motor circuit protector offers precise overcurrent protection to safeguard motors from overloads and short circuits. With a current rating of 150A and a 3-pole configuration, the FXD63A150 is well-suited for applications requiring strong and consistent motor protection.

Key Features and Benefits:

• Magnetic Trip Unit: Ensures fast and reliable response to overcurrent events, protecting motors from potential damage.
• High Interrupting Capacity: With a breaking capacity of 22kAIC at 600V and 35kAIC at 480V, it provides robust protection for high-demand environments.
• Non-Interchangeable Trip: Enhances safety by preventing unauthorized modifications, ensuring reliable, consistent performance.
• Customizable Connections: No lugs installed, allowing for flexibility in customized connection solutions tailored to specific requirements.

Technical Specifications:

• Current Rating: 150 Amps
• Poles: 3
• Voltage Rating: 600V (22kAIC) / 480V (35kAIC)
• Dimensions (W x H x D): 4.5 x 9.5 x 4 inches
• Weight: 7 lbs
• Special Features: Magnetic trip-only unit, no lugs installed

Material Compliance and Certifications:

• UL 489 Certification: Assures adherence to industry standards for safety and performance.
• IEC 60947-2 Compliance: Ensures international standards compliance for low-voltage motor protection.
• RoHS Directive Compliance: Compliant with RoHS, supporting environmental safety by being free from hazardous substances.
• WEEE Take-Back Obligation: Compliant with the Waste Electrical and Electronic Equipment (WEEE) Directive, facilitating responsible recycling and disposal.

Suitability:

• The Siemens FXD63A150 motor circuit protector is ideal for motor protection in commercial buildings, industrial facilities, and other high-demand applications. Its high interrupting capacity and robust design make it well-suited for environments with heavy-duty motors. It is an excellent choice for panel builders, OEMs, and retrofit projects, providing a reliable, compliant, and efficient solution for safeguarding motor systems.

Upgrade your motor protection with the Siemens FXD63A150, offering reliability, performance, and compliance to meet rigorous industry demands.
