FTL3200 - 200Amp Fusible Pullout

FTL3200 - 200Amp Fusible Pullout

The FTL3200 is a 200 Amp, 3-pole fusible pullout fuse holder accessory used with compatible Masterclad switchgear systems. When you're maintaining existing electrical distribution equipment, finding the correct accessory is often about matching the original specifications — current rating, pole configuration, voltage requirements, and mounting style all need to line up with the equipment already installed.

Key Features and Benefits

• 200 Amp Class T fusible pullout fuse holder
• Three-pole configuration for three-phase electrical systems
• Designed for compatible Masterclad switchgear applications
• 100kA symmetrical short-circuit rating
• Surface-mount installation design
• Screw terminal electrical connections
• Accepts aluminum and copper conductors
• Supports AWG 4 through 250 kcmil wire sizes
• Helps maintain existing switchgear configuration
• Built to last for continued service in properly maintained equipment


Technical Specifications

• Catalog Number: FTL3200

• Product Type: Fuse Holder / Fusible Pullout Accessory

• Product Family: Masterclad

• Fuse Class: Class T

• Line Rated Current: 200 Amps

• Poles: 3

• Phase: 3 Phase

• Voltage Ratings:
  • 120/240VAC
  • 240/120VAC Delta
  • 208Y/120VAC
• Short-Circuit Rating: 100kA

• Wiring Configuration:
  • 3-Wire
  • 4-Wire
• Mounting Method: Surface Mount

• Electrical Connection: Screw Terminal

• Conductor Range: AWG 4 through 250 kcmil (Aluminum/Copper)

• Dimensions:
  • Height: 6.61 in.
  • Width: 4.46 in.
  • Depth: 3.80 in.
• Approximate Shipping Weight: 4.55 lbs.


Material Compliance and Certifications

The FTL3200 is a switchgear accessory intended for use with compatible Masterclad electrical distribution equipment. It is UL Listed and should be installed by qualified electrical personnel following applicable electrical codes, safety practices, and equipment requirements.

Where It Works Best

• Commercial power distribution systems
• Industrial electrical facilities
• Manufacturing plants
• Masterclad switchgear assemblies
• Three-phase electrical distribution equipment
• Applications requiring a 200 Amp Class T fusible pullout accessory
