FJ63B100 - 100Amp Circuit Breaker

FJ63B100 - 100Amp Circuit Breaker

The FJ63B100 is a robust, high-performance molded case circuit breaker designed for demanding industrial applications where reliability and safety are paramount. With a durable construction and precise thermal magnetic trip unit, this circuit breaker ensures consistent protection against overloads and short circuits, safeguarding your electrical systems. Rated at 100 amperes with a versatile 3-pole design, the FJ63B100 is built to handle challenging environments, making it an ideal choice for maintenance tasks in existing infrastructures.

Key Features and Benefits:

• Reliable Protection: Thermal magnetic trip unit offers precise protection against overloads and short circuits, enhancing safety and reliability.
• High Interrupting Capacity: With an AIC rating of 18k @ 600VAC, 25k @ 480VAC, and 25k @ 240VAC, this breaker is designed to handle high fault currents, providing robust protection in heavy-duty applications.
• Durable Construction: Built with a molded case and designed for long-lasting performance, the FJ63B100 ensures durability in harsh industrial settings.
• Easy Installation: Includes load-side lug terminals, making installation straightforward and secure.

Technical Specifications:

• Amperage: 100 Amperes
• Poles: 3
• Dimensions: 4.50"W x 9.50"H x 4.00"D
• AIC Rating & Voltage:18k @ 600VAC;åÊ25k @ 480VAC;åÊ25k @ 240VAC
• Frame Type: FJ6
• Frequency: 50/60Hz
• Operating Temperature: 40å¼C
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Ship Weight: 14 lbs

Material Compliance and Certifications:

• Compliance: The FJ63B100 meets stringent industry standards for quality and safety, ensuring reliable operation in compliance with global regulations.
• Certifications: Certified for use in a wide range of industrial environments, this circuit breaker adheres to the necessary electrical codes and standards.

Suitability:

• The FJ63B100 circuit breaker is particularly suitable for maintenance applications in industrial and commercial environments where high reliability and safety are crucial. Its durable construction and high interrupting capacity make it an excellent choice for protecting electrical systems in existing infrastructures, ensuring continued operation without compromising safety.
