FHL36040 - 40 Amp Circuit Breaker

Discover reliable electrical protection with the FHL36040 circuit breaker by Schneider Electric — a 40-amp, 3‑pole, 600-V thermal‑magnetic unit built to safeguard industrial and commercial systems. Designed for heating, ventilation, and air‑conditioning (HVAC) setups as well as general power distribution, this HACR‑rated device delivers effective overload and short‑circuit protection in one compact package.

Key Features and Benefits

• Thermal‑magnetic protection: combines temperature‑based overload sensing with magnetic short‑circuit interruption for comprehensive coverage.
• High interrupting capacity: engineered to respond to fault currents swiftly, giving you greater system security and fewer shutdowns.
• Space‑efficient unit‑mount design: the compact footprint allows installation in tighter panel arrangements without sacrificing performance.
• Durable build for tough environments: constructed for dependable service in demanding conditions, minimizing maintenance and downtime.
• HACR‑rated: meets heating, air‑conditioning, and refrigeration system standards, making it a flexible choice for HVAC and industrial applications.
• Eco‑compliant: conforms to RoHS and REACH standards, reflecting an environment‑aware choice for your electrical infrastructure.

Technical Specifications

• Voltage rating: 600 V
• Current rating: 40 Amp
• Number of poles: 3 (3P)
• Breaking capacity code: H
• Magnetic hold current: 400 Amp
• Magnetic tripping current: 850 Amp
• Electrical connection: lug type for both load and line ends
• Dimensions:
  • Height: 6.4 in (162.56 mm)
  • Width: 4.5 in (114.30 mm)
  • Depth: 4.13 in (104.90 mm)
• Termination identifier: AL100FA
• Phase connection: ABC

Material Compliance and Certifications

• This model is UL Listed and CSA certified, providing the assurance of recognized third‑party standards.
• It also complies with RoHS and REACH environmental requirements, enabling you to specify it with confidence in regulated industries.

Where It Works Best

• If you’re installing or upgrading panelboards in commercial or industrial buildings — particularly in HVAC, refrigeration, or mixed‑use power‑distribution environments — the FHL36040 is an excellent fit. Its HACR rating makes it ideal for air‑conditioning and heating systems, yet its high fault‑handling capability means it’s equally suited for general industrial protection tasks. Whether in a tight equipment room or a harsh plant environment, this breaker offers dependable performance you can trust.
