FHL36060 - 60 Amp Circuit Breaker

FHL36060 - 60 Amp Circuit Breaker

When you're maintaining an existing electrical distribution system, finding the correct replacement breaker is about more than matching the amperage. The right circuit breaker needs to match the original equipment's ratings, mounting style, and protection characteristics to keep the system operating as intended. The Square D FHL36060 is designed for this exact purpose, providing the same form, fit, and function as compatible Square D FH equipment.

Key Features and Benefits

• Genuine Square D FHL36060 molded case circuit breaker
• 60 Amp continuous current rating
• Three-pole design for three-phase electrical systems
• Rated for 600V AC applications
• Thermal-magnetic trip technology provides overload and short-circuit protection
• Unit mount configuration for compatible Square D equipment
• Line and load lug electrical connections
• Push-to-Trip feature allows manual breaker operation without exposure to live parts
• HACR rated for heating, air conditioning, and refrigeration applications
• Helps maintain original equipment form, fit, and function
• Designed for replacement and maintenance applications
• Built to last in commercial and industrial electrical systems


Technical Specifications

• Catalog Number: FHL36060

• Manufacturer: Square D

• Product Type: Molded Case Circuit Breaker

• Series: FH

• Trip Unit Technology: Thermal-Magnetic

• Amperage Rating: 60 Amps

• Voltage Rating: 600V AC

• Number of Poles: 3

• Phase Connection: ABC (Three-Phase)

• Breaking Capacity Code: H

• Interrupting Rating: 18kA at 600VAC

• Mounting Style: Unit Mount

• Electrical Connections: Line Lugs and Load Lugs

• Terminal Identifier: AL100FA

• Magnetic Hold Current: 800 Amps

• Magnetic Tripping Current: 1,450 Amps

• Application Rating: HACR Rated

• Additional Feature: Push-to-Trip Function

• Dimensions: 6.40 in. H × 4.50 in. W × 4.13 in. D


Material Compliance and Certifications

The Square D FHL36060 is UL Listed and CSA Certified and is designed to meet recognized North American electrical safety standards. FH molded case circuit breakers are also designed to meet applicable certification requirements, including UL 489 for molded case circuit breakers. This breaker is intended for installation in compatible electrical equipment and should be installed according to the National Electrical Code (NEC) and applicable local electrical requirements. Installation and maintenance should always be performed by qualified electrical personnel following proper safety practices.

Where It Works Best

• Compatible Square D FH electrical distribution equipment
• Commercial buildings
• Industrial facilities
• Manufacturing plants
• HVAC systems
• Heating and air conditioning equipment
• Refrigeration applications
• Three-phase motor circuits
• Pumps and compressors
• Industrial machinery
• Branch circuit protection
• Electrical maintenance and replacement projects
